Running Oracle Database on Microsoft Windows is slightly different from running it on other platforms. So, of course, patching Oracle Database is also slightly different.
The Oracle Database runs as a Windows service. AutoUpgrade must re-create the service when you perform out-of-place patching so the service starts oracle.exe from the new Oracle home.
To recreate the service, you must specify the credentials of the user who runs the service. Windows allows you to store the credentials in a special file; AutoUpgrade can use that when it recreates the service.
For security purposes, AutoUpgrades deletes the credential file when it is no longer needed. For automation, however, that’s impractical because you would need to recreate the credential file every time you patch or upgrade.
AutoUpgrade now allows you to keep the file and reuse it. To do so, use the config file parameter delete_credential_file.
How To Patch Oracle Database on Windows
- Get the latest version of AutoUpgrade:
wget https://download.oracle.com/otn-pub/otn_software/autoupgrade.jar - Create an AutoUpgrade config file:
global.keystore=c:\oracle\autoupgrade\keystore patch1.source_home=c:\oracle\product\dbhome_19_26_0 patch1.target_home=c:\oracle\product\dbhome_19_27_0 patch1.sid=DB19 patch1.folder=c:\oracle\patches patch1.patch=RECOMMENDED patch1.wincredential=c:\oracle\autoupgrade\credential patch1.delete_credential_file=falsewincredentialis the location where AutoUpgrade stores the credential file.- Set
delete_credential_fileto false to keep the credential file so you can re-use it.
- Load the credentials for the user running the service into a credential file:
java -jar autoupgrade.jar -config ... –patch -load_win_credential "DB19" - Start AutoUpgrade in deploy mode:
java -jar autoupgrade.jar -config ... –patch -mode deploy- AutoUpgrade finds and downloads the right patches for Windows.
- Creates a new Oracle home with the new patches.
- Completes the entire patching process.
That’s it! You’ve patched your Oracle Database on Windows.
Here’s a little demo from our YouTube channel. Be sure to subscribe so you don’t miss out.
Happy patching!
Databases Are Fun
the “all in one“-Task works well on winodws and even better with the new version of AutoUpgrade (25.2). Using the former AutoUpgrader (25.1) to create a new OraHome “Out-Of-Place-Patching” got rarely stuck on certain customer hosts – 2 out of 20.
Bug: AUPG-4525 AutoUpgrade Patching – OPatch phase using wrong ORACLE_HOME and failing on Windows
A big thanks to Daniel who provided us with this information!
Marco
LikeLike
That’s good to hear.
Thanks for sharing your feedback!
Daniel
LikeLike
Daniel, is there a way of doing this in an air gap environment, then move between test and production. I create gold copy and deploy as new home, but also I have to request a single patch on top of windows quartaly security to deal with SQL login issue that is not being fixed and takes weeks to be supplied. Currently on 19.19 waiting on 19.28 extra patch.
LikeLike
Hi John,
Yes, there is a way. You first download the patches you need using AutoUpgrade “-mode download”. Do that on a server with access to the internet. Then transfer the files to the “air-gap” environment and run AutoUpgrade in “-mode create_home” or “-mode deploy” and be sure to set “download=no” in your config file. That’ll allow you to patch without having internet access on the database host.
That’s a good topic for a blog post – I’ll do that one of the days.
Regards,
Daniel
LikeLike
Thanks Daniel, but un clear how that gets past 29869909. Since going from using auto upgrade from 12.2 to 19.9, which was great, to then on to 19.19 hand I’ve had to request patch to create gold copy for next possible move. For reasons cant go into have not move customer on to bleeding edge..but have to have patch ready. I have no login SQL. But unclear 29869909 patch required ? Oracle go off and supply without proof of needing. I’ll give the autoupgrade down load a go….but dream of going to 23 on premise.
LikeLike
Hi John,
If patch 29869909 is a requirement in your organization, you should file a service request and request it for inclusion in future Windows bundle patches. Then, you can avoid requesting it over and over again. Please specify a good business reason for the requirement. That increases the chances for inclusion.
Having said that, the patch will not be needed for AutoUpgrade to patch your database. It doesn’t rely on login.sql or other files. You should be able to successfully patch the database without.
Regards,
Daniel
P.S. We all dream of Oracle Database 23ai on all platforms :)
LikeLike
Daniel, hit 29869909, trying to use autoupgrade going from 19.9 to 19.19. Raised at looking at 19.21 and 19.25 and now 19.28, we have to be ready to patch, but cant schedule…very big air gap. Db very much vanilla, except using versioning wsl and ols…cant understand why we are unique and got 29869909.
Did flag to Mike.Dietrich couple of years back. Oracle generated patch since 18.3 and 19.19 John
LikeLike
Hi John,
That does sound weird indeed. I know many Windows customers that use AutoUpgrade for patching and upgrading without any such issues.
If you at one point open an SR, please feel free to keep me informed.
Regards,
Daniel
LikeLike
Daniel, sorry went looking for this yesturday ….
https://mikedietrichde.com/2023/06/20/virtual-classroom-seminar-17-from-sr-to-patch/
Discussed with Mike, back in 2023. (John Hollings comment)
Not mike miss understood me “Furthermore, I never stated that you can upgrade from 12.2.0.1 to 23c”. I knew we had to go through 19 …. but was dreaming of going 19.9 to 23c … no I mean 23ai
Autoupgrade work like a dream getting from 12 to 19.9 .. but had to write stopping and starting services in powershell.
Anyhow they have just dropped 19.28 extra patch for me … I’ve asked again for fix to go in next.
I only request every other quarter… I have to reach the top of priority list of thing to fix to next deploy an patch for real … although the wider customer (not our specific one) is wanting things fixed every time a CVE is fixed.
Anyway not a auto upgrade issue, one of the software being updated.
Can’t give you my latest SR, cos can’t do 2 auth outside of work email, could someone request 2 methods of sending pin put.
John
LikeLike
Daniel, Apparently fix for 29869909 will be included in 19.30.
Regards
John
