How to Remove an Old Oracle Grid Infrastructure 19c Home

When you patch your Oracle Grid Infrastructure 19c (GI) using the out-of-place method, you should also remove the old GI homes.

I recommend that you keep the old GI home for a while. At least until you are convinced that a rollback is not needed. Once you are comfortable with the new GI home, you can safely get rid of it.

How to Remove an Oracle Grid Infrastructure 19c Home

  1. I set the path to my old GI home as an environment variable:
    export REMOVE_ORACLE_HOME=/u01/app/19.0.0.0/grid
  2. Optionally, I take a backup of the GI home for safekeeping:
    export GOLDIMAGEDIR=/u01/app/grid/goldimages
mkdir -p $GOLDIMAGEDIR
$REMOVE_ORACLE_HOME/gridSetup.sh -createGoldImage \
   -destinationLocation $GOLDIMAGEDIR \
   -silent
  3. I verify that the GI home, is not the active one. This command returns the active GI home. It must not return the path of the GI home, which I want to delete. As grid:
    $REMOVE_ORACLE_HOME/srvm/admin/getcrshome
  4. I double-check that the GI home to remove is not the active one. The XML tag returned must not contain an CRS=“true” attribute. As grid:
    export ORA_INVENTORY_XML=/u01/app/oraInventory/ContentsXML/inventory.xml
grep "$REMOVE_ORACLE_HOME" $ORA_INVENTORY_XML

#This is good
#   <HOME NAME="OraGrid190" LOC="/u01/app/19.0.0.0/grid" TYPE="O" IDX="1"/>
#This is bad
#.  <HOME NAME="OraGrid190" LOC="/u01/app/19.0.0.0/grid" TYPE="O" IDX="1" CRS="true"/>
  5. I run the deinstall tool. I switch to my home directory to ensure I am not interfering with the de-installation. As grid:
    cd ~
$REMOVE_ORACLE_HOME/deinstall/deinstall
    The script:
    • Detects the nodes in my cluster.
    • Prints a summary and prompts for confirmation.
    • Deinstalls the GI home on all nodes.
    • Instructs me to run a script as root on all nodes.
    • Prints a summary including any manual tasks in the end.
  6. I verify that the GI home is marked as deleted in the inventory. The XML tag should have a Removed=“T” attribute. As grid:
    export ORA_INVENTORY_XML=/u01/app/oraInventory/ContentsXML/inventory.xml
grep "$REMOVE_ORACLE_HOME" $ORA_INVENTORY_XML

#This is good
#   <HOME NAME="OraGrid190" LOC="/u01/app/19.0.0.0/grid" TYPE="O" IDX="1" Removed="T"/>
  7. Often the deinstall tool can’t remove some files because of missing permissions. I remove the GI home manually. As root on all nodes:
    export REMOVE_ORACLE_HOME=/u01/app/19.0.0.0/grid
rm -rf $REMOVE_ORACLE_HOME

Silent Mode

There is also a silent mode if you want to script the removal. Check the -checkonly and -silent parameters in the documentation.

You can also find a sample response file in the documentation.

Appendix

Further Reading

Other Blog Posts in This Series

How to Apply Patches Out-of-place to Oracle Grid Infrastructure and Oracle Data Guard Using Standby-First

I strongly recommend that you always patch out-of-place. Here’s an example of how to do it on Oracle Grid Infrastructure (GI) and Oracle Data Guard using Standby-First Patch Apply.

Standby-First Patch Apply allows you to minimize downtime to the time it takes to perform a Data Guard switchover. Further, it allows you to test the apply mechanism on the standby database by temporarily converting it into a snapshot standby database.

The scenario:

  • Oracle Grid Infrastructure 19c and Oracle Database 19c
  • Patching from Release Update 19.17.0 to 19.19.0
  • Vertical patching – GI and database at the same time
  • Data Guard setup with two RAC databases
    • Cluster 1: copenhagen1 and copenhagen2
    • Cluster 2: aarhus1 and aarhus2
    • DB_NAME: CDB1
    • DB_UNIQUE_NAME: CDB1_COPENHAGEN and CDB1_AARHUS
  • Using Data Guard broker
  • Patching GI using SwitchGridHome method

Let’s get started!

Step 1: Prepare

I can make the preparations without interrupting the database.

Step 2: Restart Standby in New Oracle Homes

Now, I can move the standby database to the new GI and database homes.

  • On the standby hosts, aarhus1 and aarhus2, I first move the database configuration files from the old database home to the new one.

  • I change the database configuration in GI. Next time the database restarts, it will be in the new Oracle Home:

    [oracle@aarhus1]$ $OLD_ORACLE_HOME/bin/srvctl modify database \
   -db $ORACLE_UNQNAME \
   -oraclehome $NEW_ORACLE_HOME

  • I switch to the new GI on all standby hosts, aarhus1 and aarhus2, by executing step 2 (Switch to the new Grid Home) of the SwitchGridHome method.

    • It involves running gridSetup.sh ... -switchGridHome and root.sh.
    • You can perform the switch in a rolling manner or all at once.
    • The switch restarts the standby database instance. The standby database instance restarts in the new Oracle Home.
    • If the profile of grid (like .bashrc) sets the ORACLE_HOME environment variable, I ensure to update it.

  • If I had multiple standby databases, I would process all standby databases in this step.

Step 3: Test Standby Database

This is an optional step, but I recommend that you do it.

  • I convert the standby database (CDB1_AARHUS) to a snapshot standby database:
    DGMGRL> convert database CDB1_AARHUS to snapshot standby;
  • I test Datapatch on the standby database. It is important that I run the command on the standby database:
    [oracle@aarhus1]$ $ORACLE_HOME/OPatch/datapatch -verbose
  • I can also test my application on the standby database.
  • At the end of my testing, I revert the standby database to a physical standby database. The database automatically reverts all the changes made during testing:
    DGMGRL> convert database CDB1_AARHUS to physical standby;

Step 4: Switchover

I can perform the previous steps without interrupting my users. This step requires a maintenance window because I am doing a Data Guard switchover.

  • I check that my standby database is ready to become primary. Then, I start a Data Guard switchover:
    DGMGRL> connect sys/<password> as sysdba
DGMGRL> validate database CDB1_AARHUS;
DGMGRL> switchover to CDB1_AARHUS;

A switchover does not have to mean downtime.

If my application is configured properly, the users will experience a brownout; a short hang, while the connections switch to the new primary database.

Step 5: Restart New Standby in New Oracle Homes

Now, the primary database runs on aarhus1 and aarhus2. Next, I can move the new standby hosts, copenhagen1 and copenhagen2, to the new GI and database homes.

  • I repeat step 2 (Restart Standby In New Oracle Homes) but this time for the new standby hosts, copenhagen1 and copenhagen2.

Step 6: Complete Patching

Now, both databases in my Data Guard configuration run out of the new Oracle Homes.

Only proceed with this step once all databases run out of the new Oracle Home.

I need to run this step as fast as possible after I have completed the previous step.

  • I complete the patching by running Datapatch on the primary database (CDB1_AARHUS). I add the recomp_threshold parameter to ensure Datapatch recompiles all objects that the patching invalidated:

    [orale@aarhus1]$ $ORACLE_HOME/OPatch/datapatch \
   -verbose \
   -recomp_threshold 10000
    • I only need to run Datapatch one time. On the primary database and only on one of the instances.

  • I can run Datapatch while users are connected to my database.

  • Optionally, I can switch back to the original primary database on copenhagen1 and copenhagen2, if I prefer to run it there.

That’s it. Happy patching!

Appendix

Further Reading

Other Blog Posts in This Series

Files to Move During Oracle Database Out-Of-Place Patching

I strongly recommend that you patch your Oracle Database using the out-of-place method. It has many advantages over in-place patching. But when you move your Oracle Database from one Oracle Home to another, you also need to move a lot of files.

Which files are that, and how can you make it easier for you? Also, some files might exist already in the target Oracle Home; what do you do then?

Files to Move

Password File

Linux:

dbs/orapw<ORACLE_SID>

Windows:

database\pwd<ORACLE_SID>.ora

You can override the default location in Windows using the following registry entries:

ORA_<ORACLE_SID>_PWFILE
ORA_PWFILE

If you use Grid Infrastructure, you can put the password file outside of the Oracle Home:

srvctl modify datatabase \
   -d $ORACLE_UNQNAME
   -pwfile <NEW_LOCATION_OUTSIDE_ORACLE_HOME>

I recommend storing it in ASM.

Parameter Files

Linux:

dbs/init<ORACLE_SID>.ora
dbs/spfile<ORACLE_SID>.ora

Windows:

database\init<ORACLE_SID>.ora
database\spfile<ORACLE_SID>.ora

Parameter files may include other files using the IFILE parameter.

You can redirect the server parameter file to a location outside the Oracle Home using the SPFILE parameter in your parameter file. If you use Grid Infrastructure, you can also redirect the server parameter file:

srvctl modify datatabase \
   -d $ORACLE_UNQNAME
   -spfile <NEW_LOCATION_OUTSIDE_ORACLE_HOME>

I recommend storing it in ASM.

Oratab

You need to update the database instance entry in the oratab file:

/etc/oratab

On Solaris, you find the file in:

/var/opt/oracle/oratab

On Windows, the file does not exist. Instead, you re-register the instance in the registry when you use oradim.exe.

Profile Scripts

Many people have profile scripts that set the environment to a specific database. Be sure to update the Oracle Home in such scripts.

Network Files

Network configuration files:

network/admin/ldap.ora
network/admin/listenener.ora
network/admin/sqlnet.ora
network/admin/tnsnames.ora

tnsnames.ora, sqlnet.ora and listener.ora can include contents from other files using the IFILE parameter, although the support of it is somewhat… questionable according to Allows for IFILE Ifile Support and Oracle Net (Doc ID 1339269.1).

You can redirect the files using the TNS_ADMIN environment variable. On Windows, you can also redirect using the TNS_ADMIN registry entry. If you use Grid Infrastructure, you can set the TNS_ADMIN environment variable as part of the cluster registration:

srvctl setenv database \
   -d $ORACLE_UNQNAME \
   -env "TNS_ADMIN=<NEW_LOCATION_OUTSIDE_ORACLE_HOME>"

Data Guard Broker Config Files

Linux:

dbs/dr1<ORACLE_SID>.dat
dbs/dr2<ORACLE_SID>.dat

Windows:

database\dr1<ORACLE_SID>.dat
database\dr2<ORACLE_SID>.dat

You can redirect the broker config files using the parameter DG_BROKER_CONFIG_FILEn:

alter system set db_broker_start=false;
alter system set dg_broker_config_file1='<NEW_LOCATION>/dr1<ORACLE_SID>.dat';
alter system set dg_broker_config_file2='<NEW_LOCATION>/dr2<ORACLE_SID>.dat';
alter system set db_broker_start=true;

I recommend storing the files in ASM.

Admin directory

admin subdirectory in Oracle Home:

admin

If you don’t set ORACLE_BASE environment variable, the database uses the Oracle Home for that location. It can contain diagnostic information like logs and tracing which you might want to move to the new Oracle Home.

In rare cases, the TDE keystore will go in there as well. This is definitely a folder that you want to keep.

admin/$ORACLE_UNQNAME/wallet

I recommend having a dedicated ORACLE_BASE location. Always set ORACLE_BASE environment variable for all databases. This will ensure that the database will not create an admin directory in the Oracle Home.

If you use TDE Tablespace Encryption, I strongly recommend that you store the database keystore outside of the Oracle Home using the WALLET_ROOT parameter.

Direct NFS

The Direct NFS configuration file:

dbs/oranfstab

The file might exist in the target Oracle Home, in which case you must merge the contents.

Typically, on Windows, the files from dbs are stored in database folder. But that’s different for this specific file (thanks Connor for helping out).

Centrally Managed Users

One of the default locations of the configuration file for Active Directory servers for centrally managed users is.

ldap/admin/dsi.ora

I recommend using the LDAP_ADMIN environment variable to redirect the file to a location outside of the Oracle Home.

LDAP

Configuration of Directory Usage Parameters:

ldap/admin/ldap.ora

I recommend using the LDAP_ADMIN or TNS_ADMIN environment variable to redirect the file to a location outside of the Oracle Home.

Oracle Messaging Gateway

The Messaging Gateway default initialization file:

mgw/admin/mgw.ora

The file might exist in the target Oracle Home, in which case you must merge the contents.

Oracle Database Provider for DRDA

Configuration file for Oracle Database Provider for DRDA:

drdaas/admin/drdaas.ora

The file might exist in the target Oracle Home, in which case you must merge the contents.

Oracle Text

If you use Oracle Text, you can generate a list of files that you must copy to the target Oracle Home:

ctx/admin/ctx_oh_files.sql

Oracle Database Gateway for ODBC

ODBC gateway initialization file:

hs/admin/init<ORACLE_SID>.ora

External Procedures

You can define the environment for external procedures in extproc.ora. Such configuration might exist in the target Oracle Home already, in which case you must merge the contents:

hs/admin/extproc.ora

Other Things to Consider

Enterprise Manager

After moving the database to a new Oracle Home, you need to reconfigure the target in Enterprise Manager. The Oracle Home path is part of the configuration. You can easily change it with emcli:

emcli modify_target \
   -type='oracle_database' \
   -name='<target_name>' \
   -properties='OracleHome:<new_oracle_home_path>'

Also, if you moved the listener as part of the patching to a new Oracle Home, you need to update that as well.

On My Oracle Support you can find an example on how to bulk update multiple targets.

In a future version of AutoUpgrade, it will be able to modify the target in Enterprise Manager for you.

Oracle Key Vault

There should be no additional configuration needed if you are using Oracle Key Vault and you move the database to a new Oracle Home.

You can find information on how to configure Oracle Key Vault in an Oracle Database in the documentation.

ZDLRA

When you patch out-of-place, you should always ensure that the target Oracle Home has the latest version of libra.so. AutoUpgrade does not copy this file for you, because there is no way to tell which version is the latest version.

Ideally, you configure ZDLRA in via sqlnet.ora and store the wallet outside of the Oracle Home. If so, the ZDLRA configuration works in the target Oracle Home because AutoUpgrade takes care of sqlnet.ora.

If you use ra_install.jar to configure ZDLRA, the script will:

  • Create a file: $ORACLE_HOME/dbs/ra<ORACLE_SID>.ora
  • Create a folder with a wallet: $ORACLE_HOME/dbs/wallet

In this case, you must manually copy the files to the target Oracle Home. You can avoid this by using sqlnet.ora for the configuration instead.

AutoUpgrade does not copy these files for you, because of the issue described above with libra.so.

Database Directories

You must update certain internal database directories, when you move the database to a new Oracle Home. The easiest way is to run:

@?/rdbms/admin/utlfixdirs.sql

In multitenant, you need to run the script in CDB$ROOT only.

On My Oracle Support you find a list of all the directories that you must update if you don’t use the script above.

In a future version of AutoUpgrade, it will change all the applicable directories for you automatically.

How to Make It Easy

Use AutoUpgrade

The easiest way to patch your Oracle Database is to use AutoUpgrade. It takes care of everything for you (unless stated otherwise above). You need a config file:

patch1.source_home=/u01/app/oracle/product/19.18.0
patch1.target_home=/u01/app/oracle/product/19.19.0
patch1.sid=MYDB

Then you start AutoUpgrade:

java -jar autoupgrade.jar -config mydb.cfg -mode deploy

That’s it! You don’t need to worry about all those configuration files. AutoUpgrade got you covered.

Use Read-Only Oracle Home

If you use Read-Only Oracle Home, the process is slightly easier.

You can’t store any custom files in the Oracle Home. Instead, you store all configuration files in Oracle Base Home; a directory outside the Oracle Home. You can find all the files you need to copy in Oracle Base Home.

When you create a new Read-Only Oracle Home, the installer will create a new Oracle Base Home specifically for that new Oracle Home. As part of the patching, you move the files into that new Oracle Base Home.

Conclusion

Did I miss any files? Please leave a comment if you move other files when you patch out-of-place.
