Transparent Data Encryption and Multitenant

In a multitenant environment where you want to use Transparent Data Encryption (TDE), you can do it in two ways:

  • United keystore mode. The default option. The CDB has a keystore, and all PDBs use that keystore. The encryption keys belong to each individual PDB, but the one keystore contains all the encryption keys.
  • Isolated keystore mode. Became available with 19.11.0 and in later versions. The CDB has a keystore that all PDBs can use, but you can configure a PDB to use its own keystore. If a PDB uses TDE in isolated mode, that PDB will physically have its own keystore, where only the TDE encryption keys get stored. PDBs that are not configured to use isolated mode, will put the encryption keys into the keystore of the CDB. Isolated mode is fairly new and is not fully supported yet by AutoUpgrade, OCI tooling, and other tools.

United mode is the easy way of doing things. You configure one keystore and then all PDBs can use that keystore.

Isolated mode is suitable when you want to completely isolate the PDBs and even keep the encryption keys separate. Moreover, you can have different passwords protecting the keystores. Isolated mode strengthens security but adds maintenance overhead; more keystores to backup and protect). Additionally, in isolated mode, each PDB can use a different kind of keystore. The CDB can use a software keystore (a file in the OS), PDB1 can use its own software keystore (another file in the OS), and PDB2 can store its encryption keys in Oracle Key Vault. More security and more flexibility.

Regardless of which keystore mode you plan to use, you always start by configuring TDE in united mode in the CDB. Afterward you can enable isolated mode in individual PDBs, if you want that.

How To Configure TDE

This procedure enables TDE in united mode. I will use a software keystore (a file in the OS):

  1. Create a directory where I will place the keystore. You can change $ORA_KEYBASE to another location.

    export ORA_KEYBASE=$ORACLE_BASE/admin/$ORACLE_SID/wallet
    #Don't change ORA_KEYSTORE
    export ORA_KEYSTORE=$ORA_KEYBASE/tde
    mkdir -p $ORA_KEYSTORE

  2. Configure WALLET_ROOT to tell the database where I want to create the keystore files, and TDE_CONFIGURATION to tell the database to use a software keystore:

    alter session set container=cdb$root;
    alter system set wallet_root='$ORA_KEYBASE' scope=spfile;
    shutdown immediate
    startup
    alter system set tde_configuration='KEYSTORE_CONFIGURATION=FILE' scope=both;

  3. Now create the keystore and a TDE encryption key for CDB$ROOT. My TDE keystore password is oracle_4U; you should pick a better password:

    administer key management create keystore '$ORA_KEYSTORE' identified by "oracle_4U";
    administer key management set keystore open force keystore identified by "oracle_4U";
    administer key management set key identified by "oracle_4U" with backup;


    You can optionally use the CONTAINERS=ALL clause to set a TDE encryption key in all PDBs. Don’t do this if you plan on using isolated keystore later on:

    administer key management create keystore '$ORA_KEYSTORE' identified by "oracle_4U";
    administer key management set keystore open force keystore identified by "oracle_4U" container=all;
    administer key management set key identified by "oracle_4U" with backup container=all;

  4. Optionally, create an auto-login keystore. If you don’t, you must manually input the TDE keystore password every time the database starts.

    administer key management create local auto_login keystore from keystore '$ORA_KEYSTORE' identified by "oracle_4U";


That’s it. You can now start to create encrypted tablespaces:

create tablespace ... encryption encrypt;

I have now created the root keystore in the location defined by WALLET_ROOT. The database automatically adds a subfolder called tde. In that folder you find ewallet.p12 which is the actual software keystore of the CDB, and cwallet.sso which is the auto-login keystore:

$ pwd
/u01/app/oracle/admin/CDB2/wallet/tde
$ ll
total 8
-rw-------. 1 oracle dba 4040 May 16 09:35 cwallet.sso
-rw-------. 1 oracle dba 3995 May 16 09:35 ewallet.p12

Configure Isolated Keystore

You can enable isolated mode in a PDB after you configure the CDB for united mode (the above procedure). The following assumes that TDE has not been configured yet in PDB1:

  1. Switch to the PDB and configure TDE_CONFIGURATION:
    ALTER SESSION SET CONTAINER=PDB1;
    ALTER SYSTEM SET TDE_CONFIGURATION='KEYSTORE_CONFIGURATION=FILE' SCOPE=BOTH;

  2. Create the keystore and a TDE encryption key for the PDB. Notice I am giving my PDB keystore a different password:
    ADMINISTER KEY MANAGEMENT CREATE KEYSTORE IDENTIFIED BY "oracle_4U2";
    ADMINISTER KEY MANAGEMENT SET KEYSTORE OPEN FORCE KEYSTORE IDENTIFIED BY "oracle_4U2";
    ADMINISTER KEY MANAGEMENT SET KEY IDENTIFIED BY "oracle_4U2" WITH BACKUP;

  3. Optionally, create an auto-login keystore of the PDB keystore. If not, you need to manually input the TDE keystore password in the PDB every time it starts:
    ADMINISTER KEY MANAGEMENT CREATE LOCAL AUTO_LOGIN KEYSTORE FROM KEYSTORE IDENTIFIED BY "oracle_4U2";


The PDB keystore is now placed in a subfolder of WALLET_ROOT matching the PDB GUID (D6A29777EC214B6FE055000000000001). You find similar files, ewallet.p12 and cwallet.sso in the dedicated folder for the isloated PDB keystore:

$ pwd
/u01/app/oracle/admin/CDB2/wallet/D6A29777EC214B6FE055000000000001/tde
$ ll
total 8
-rw-------. 1 oracle dba 2120 May 16 09:37 cwallet.sso
-rw-------. 1 oracle dba 2059 May 16 09:35 ewallet.p12

To get the GUID of a PDB:

select name, guid from v$containers;

The database will automatically create the directories needed for the PDB keystore.

Migrating Between Keystore Modes

If you need to migrate between the two keystore modes, there are two commands you can use. oracle_4U is the keystore password of the root keystore; oracle_4U2 is the keystore password of the PDB keystore.

To migrate a PDB from united to isolated mode, i.e., to isolate a keystore:

alter session set container=PDB1;
administer key management
   force isolate keystore identified by "oracle_4U2"
   from root keystore force keystore identified by "oracle_4U"
   with backup;

To migrate a PDB from isolated to united mode, i.e., to unite a PDB keystore into a root keystore:

alter session set container=PDB1;
administer key management
   unite keystore identified by "oracle_4U2"
   with root keystore force keystore identified by "oracle_4U"
   with backup;

To determine which keystore mode is in use:

select con_id, wrl_parameter, keystore_mode
   from v$encryption_wallet;

Final Notes

If you want to use isolated keystore mode in 19.11, 19.12 or 19.13 you need to apply patch 32235513 as well. From 19.14 and onwards this is not needed.

Isolated mode used to be a cloud-only feature. But since 19.11 it has been made available to everyone.

Further Reading

Upgrading an Encrypted Non-CDB and Converting To PDB

Converting an encrypted non-CDB to a PDB requires the keystore passwords of the non-CDB and the target CDB. You can do it with AutoUpgrade, and you can upgrade in the same operation.

How To

The Oracle Database DB12 is encrypted and on Oracle Database 12.2. I want to upgrade, convert, and plug it into CDB2 on Oracle Database 19c.

  1. Ensure that AutoUpgrade is version 22.2 or higher:
    $ java -jar autoupgrade.jar -version

  2. Create your AutoUpgrade config file and set global.keystore as specified in a previous blog post:
    global.autoupg_log_dir=/u01/app/oracle/cfgtoollogs/autoupgrade
    global.keystore=/u01/app/oracle/admin/autoupgrade/keystore

    upg1.log_dir=/u01/app/oracle/cfgtoollogs/autoupgrade/DB12
    upg1.source_home=/u01/app/oracle/product/12.2.0.1
    upg1.target_home=/u01/app/oracle/product/19
    upg1.sid=DB12
    upg1.target_cdb=CDB2

  3. Analyze:
    $ java -jar autoupgrade.jar -config DB12.cfg -mode analyze

  4. The summary report warns me that TDE keystore passwords are needed:
    [Stage Name]    PRECHECKS
    [Status]        FAILURE
    [Start Time]    2022-03-29 12:42:32
    [Duration]
    [Log Directory] /u01/app/oracle/cfgtoollogs/autoupgrade/DB12/DB12/100/prechecks
    [Detail]        /u01/app/oracle/cfgtoollogs/autoupgrade/DB12/DB12/100/prechecks/db12_preupgrade.log
                Check failed for DB12, manual intervention needed for the below checks
                [TDE_PASSWORDS_REQUIRED]

    There are more details in the preupgrade log file:
    ==============
    BEFORE UPGRADE
    ==============

    	REQUIRED ACTIONS
    	================
    		1.  Perform the specified action ...
    		ORACLE_SID                      Action Required
    		------------------------------  ------------------------
    		CDB2                            Add TDE password
    		DB12                            Add TDE password

  5. Add the TDE keystore passwords into the AutoUpgrade keystore:
    $ java -jar autoupgrade.jar -config DB12.cfg -load_password

    TDE> add DB12
    Enter your secret/Password:
    Re-enter your secret/Password:
    TDE> add CDB2
    Enter your secret/Password:
    Re-enter your secret/Password:

  6. Save the passwords into the AutoUpgrade keystore. I choose to create an auto-login keystore:
    TDE> save
    Convert the keystore to auto-login [YES|NO] ? YES
    TDE> exit

  7. Re-analyze the database:
    $ java -jar autoupgrade.jar -config DB12.cfg -mode analyze

  8. If AutoUpgrade does not report any other problems, start the upgrade and conversion. Since I chose to create an AutoUpgrade auto-login keystore, I don’t have to provide the password when AutoUpgrade starts:
    $ java -jar autoupgrade.jar -config DB12.cfg -mode deploy

  9. That’s it!

What Happens

  • First, AutoUpgrade upgrades the database to Oracle Database 19c. This is a regular non-CDB database upgrade. It requires an auto-login keystore.
  • After the upgrade, AutoUpgrade exports the encryption keys into a file. To avoid writing the encryption keys in clear text in the export file, the database needs a passphrase (transport secret) to encrypt the encryption key. AutoUpgrade generates a passphrase and stores it in the AutoUpgrade keystore. In addition, the database needs the keystore password. This is the WITH SECRET and IDENTIFIED BY clauses of the ADMINISTER KEY MANAGEMENT EXPORT KEYS statement.
  • The encryption keys is imported into CDB$ROOT of the target CDB. To load the encryption keys from the export file, the database needs the passphrase and keystore password (of the target CDB). AutoUpgrade gets both password from the AutoUpgrade keystore. This is the WITH SECRET and IDENTIFIED BY clauses of the ADMINISTER KEY MANAGEMENT IMPORT KEYS statement.
  • The pluggable database is created from the manifest file using CREATE PLUGGABLE DATABASE statement.
  • AutoUpgrade executes the ADMINISTER KEY MANAGEMENT IMPORT KEYS statement again – this time while connected to the PDB itself.
  • Finally, AutoUpgrade completes the PDB conversion by running noncdb_to_pdb.sql.

The encryption keys are imported two times – first in CDB$ROOT and then in the PDB itself. AutoUpgrade must import into CDB$ROOT if the PDB has any of the system tablespaces (SYSTEM or SYSAUX) or the undo tablespace encrypted.

Fallback

AutoUpgrade fallback functionality also works for an upgrade and PDB conversion. But there are a few requirements:

  • A target_pdb_copy_option must be specified.
  • The database must be Enterprise Edition.
  • A guaranteed restore point must be created (default behavior).

It is not possible to revert the PDB conversion. To fall back the data files must be copied as part of the PDB conversion. You specify that the data files are copied by using the config file parameter target_pdb_copy_option. As an example, if I want to copy the data files during plug-in and generate OMF names, I use this parameter:

upg1.target_pdb_copy_option=file_name_convert=NONE

AutoUpgrade automatically creates a guaranteed restore point in the beginning of an upgrade. AutoUpgrade will issue a FLASHBACK DATABASE statement to revert the upgrade. The parameter restoration governs the creation of the restore point. The default value is YES, meaning AutoUpgrade creates a guaranteed restore point, and fallback is possible.

If all prerequisites are met, I can revert the entire operation and return the database to the original state (from 19c PDB back into a 12.2 non-CDB). 103 is the job id of the upgrade/PDB conversion:

$ java -jar autoupgrade.jar -config PDB1.cfg -restore -jobs 103

Other Blog Posts in This Series

AutoUpgrade and Transparent Data Encryption (TDE)

It is now easier to upgrade and convert your encrypted Oracle Database. The latest version of AutoUpgrade adds much better support for Oracle Databases that are encrypted with Transparent Data Encryption (TDE).

You must ensure that you are using the latest version of AutoUpgrade. You can download it from My Oracle Support AutoUpgrade Tool (Doc ID 2485457.1). At the time of writing, the latest version of AutoUpgrade is 22.2:

$ java -jar autoupgrade.jar -version
build.version 22.2.220324

AutoUpgrade Keystore

Dealing with TDE, also means dealing with sensitive information. AutoUpgrade must adequately protect the TDE keystore passwords. To do so, AutoUpgrade can have its own keystore to store sensitive information, i.e., TDE keystore passwords. Whenever a TDE keystore password is needed, e.g., during an unplug-plug upgrade of an encrypted PDB, it can get the password from the AutoUpgrade keystore.

You need to tell AutoUpgrade where it can create the keystore. You do so in the config file:

global.keystore=/etc/oracle/keystores/autoupgrade/DB12

When you start to use the AutoUpgrade keystore the following files are created in the directory:

$ pwd
/etc/oracle/keystores/autoupgrade/DB12

$ ll
-rw-------. 1 oracle dba 765 Mar 28 14:56 cwallet.sso
-rw-------. 1 oracle dba 720 Mar 28 14:56 ewallet.p12

It is similar to other keystores that Oracle Database use. ewallet.p12 is the keystore, and cwallet.sso is an auto-login keystore used to open the real keystore. You don’t have to create an auto-login keystore.

You should protect the AutoUpgrade keystore files like you protect any other Oracle Database keystore:

  • Apply restrictive file system permissions.
  • Audit access.
  • Back it up.

Using the Keystore

Create your AutoUpgrade config file and specify global.keystore as described above. Start an interactive prompt that allows you to add the necessary passwords:

$ java -jar autoupgrade.jar -config DB12.cfg -load_password

The first time you use the AutoUpgrade keystore, you must provide a password that protects the AutoUpgrade keystore:

Starting AutoUpgrade Password Loader - Type help for available options
Creating new keystore - Password required
Enter password:
Enter password again:
Keystore was successfully created

In the TDE console, the following commands are available:

  • add
  • delete
  • list
  • save
  • help
  • exit

The SID references the databases. If you want to add a TDE password for the database DB12, use the following command:

TDE> add DB12
Enter your secret/Password:
Re-enter your secret/Password:
TDE> add CDB2
Enter your secret/Password:
Re-enter your secret/Password:

If you want to delete the TDE password for DB12:

TDE> delete DB12

Keystore Password is required prior to operation
Enter wallet password:

When you save the passwords into the AutoUpgrade keystore, you must decide whether you want to have an auto-login keystore:

TDE> save
Convert the keystore to auto-login [YES|NO] ?

I recommend using auto-login keystores. If you do not create an AutoUpgrade auto-login keystore, you will be prompted for the AutoUpgrade keystore password when you start AutoUpgrade. If you want to use AutoUpgrade in noconsole mode (-noconsole), then an auto-login keystore is required.

I will show how to upgrade and convert encrypted databases in later blog posts.

Loss of AutoUpgrade Keystore

What happens if your AutoUpgrade keystore is lost? This is fairly simple. You can re-create the keystore and load all passwords into it using the load_password command line option as described above.

Preupgrade Checks

We have added new preupgrade checks to the analyze phase in AutoUpgrade. These checks will help you to provide the needed passwords and ensure your TDE configuration meets certain standards:

  • auto_login_keystore_required
  • keystore_conflict
  • no_keystore_files
  • tde_passwords_required
  • wallet_root
  • tde_in_use
  • oracle_home_keystore

You can read more about these checks in MOS note Database Preupgrade tool check list. (Doc ID 2380601.1).

Further Reading

Other Blog Posts in This Series

Upgrade & Plug In: With ASM, Data Guard, TDE and no Keystore Password

I was helping a customer the other day together with Mike. They were upgrading from 18c to 19c and had to convert the database to a PDB as well. At first glance, it seemed pretty straightforward, but things got complicated because:

  • They have standby databases and want the Data Guard setup to survive the plug-in operation.
  • They are using ASM.
  • They are using TDE Tablespace Encryption and have also encrypted their SYSTEM and SYSAUX tablespace.
  • The DBA that will carry out the upgrade and plug-in is not allowed to have the TDE Keystore password. They have separation of duties, so only the security admins have the keystore password.

Can you do that? Yes, you can! Let me tell you how.

Upgrade

First, upgrade the database. You can easily maintain the Data Guard setup during an upgrade. I wrote a blog post about a little while ago. In addition, to upgrade a database with encrypted tablespaces you don’t need the keystore password. You must configure the database to use an auto login keystore, and that’s it. If you are concerned about the use of an auto-login keystore, you can simply remove it again after the upgrade.

External Store for a Keystore Password

The plug-in operation will require the keystore password. But the DBA doesn’t know it – so we need to find a solution for that. The solution is to store the keystore password in an external store. I also wrote a blog post about that a while ago. When you have it configured you can exchange the commands that require a keystore password, like:

SQL> ADMINISTER KEY MANAGEMENT ... KEYSTORE IDENTIFIED BY "S3c3tPassw0rd";

With this:

SQL> ADMINISTER KEY MANAGEMENT ... KEYSTORE IDENTIFIED BY EXTERNAL STORE;

The database will get the keystore password from an external store, which is basically a file in the file system which is encrypted with a password that only the database know.

The security admins would need to do this in the CDB that will receive the non-CDB database. They can do it in advance, so they can relax while the DBA carries out the operation in a maintenance window. If the TDE keystore is already configured using the WALLET_ROOT parameter, you can use the feature right away. Otherwise, you need a database restart to configure it.

Like with the auto-login keystore, if you are concerned about the security, you can simply disable it again after the operation.

Plug In

Now things get complicated. When you plug in your non-CDB database the manifest file contains information on where the data files are located – but only on the primary database. This is an extract of a manifest file (the one you create with DBMS_PDB.DESCRIBE):

<PDB>
  ...
  <tablespace>
    <name>SYSTEM</name>
    ...
	<file>
      <path>+DATA/SALES1/DATAFILE/system.311.1058127529</path>

After plug-in, the CDB can start to use the data files right away. It reads from the manifest files where the data files are located. But there is no information on where files are located on the standby database. To overcome this you must create aliases in the ASM instance on the standby host. The aliases will point back to the original data files (used by the standby database). So, when the plug-in happens and redo start to flow to the standby database, it will know which data files to recover. If you are storing data files in a regular file system, you could use soft links to serve the same purpose.

The procedure is already very well described:

I won’t repeat the procedure as the above articles are really good. But these articles don’t consider the situation where your SYSTEM and/or SYSAUX tablespace is encrypted.

If that is the case, you must import your encryption keys into CDB$ROOT before you execute the CREATE PLUGGABLE DATABASE command. In Reusing the Source Standby Database Files When Plugging a non-CDB as a PDB into the Primary Database of a Data Guard Configuration (Doc ID 2273304.1) it should happen right before step 17.2.2:

SQL> alter session set container=CDB$ROOT;
SQL> administer key management import keys ... keystore identified by external store ... ;
SQL> --Continue with step 17.2.2
SQL> create pluggable database .... ;

Dots and Underscores

When you follow the MOS notes you might wonder why the dots in the ASM aliases are replaced with underscores. At first glance, I had no idea, but it worked. I later learned the following:

The format for an ASM filename is [filetype|tablespacename].[ASM file number].[file incarnation], but basically it is three pieces of name separated by periods. We can’t create any filename or alias that mimics that format. So the scripts change those periods to underscores (‘_’). That is allowed.

ORA-15032 and ORA-15046

Most likely you get this error because there are already existing aliases on the ASM file. Only one alias is allowed per file.

  1. You can verify that by using the ls command in ASMCMD. If it is an alias the Name column will look similar to this alias1 => +DATA/......
  2. Ensure the database is not using the alias. If it does, rename the file in the database.
  3. Remove the alias from ASM. It is strongly recommended to use rmalias. Although also possible with rm I consider it much safer to use rmalias.

Conclusion

You can upgrade and convert your database to a PDB without comprising your standby database. In addition to that, you can configure your database in such a way that you don’t even need to type in the TDE keystore password.

How to Stop Hardcoding Your TDE Keystore Password

When you encrypt your databases, you will often end up needing the keystore password to perform certain operations. For instance, cloning an encrypted PDB will require the keystore password:

CREATE PLUGGABLE DATABASE ... KEYSTORE IDENTIFIED BY S3cr3t;

This is not very secure because the keystore password is now visible in clear text. Further, if you have the command in a script, ansible, cron job or the like, you will also have it there in clear text. Or, if your organization has implemented separation of duties, and the operational DBAs don’t have access to the keystore password.

Enter Secure External Password Store (SEPS)

Using the example above, what if you could just write the following:

CREATE PLUGGABLE DATABASE ... KEYSTORE IDENTIFIED BY EXTERNAL STORE;

And the database would get the secret keystore password without involving you! Your problems would be solved.

That is what you can do with Secure External Password Store. Whenever you need to specify the keystore password using KEYSTORE IDENTIFIED BY you can use the EXTERNAL STORE clause, and avoid typing the password.

SEPS was introduced in 10g, however, since Oracle Database 12.2 you can store keystore credentials in it. SEPS is similar to an auto-login keystore. It is an encrypted file stored in the file system that is encrypted by a password that only the database knows. You as a DBA can’t extract the information from the database.

Configuration

First, tell the database where SEPS is located:

SQL> ALTER SYSTEM
     SET EXTERNAL_KEYSTORE_CREDENTIAL_LOCATION = '$ORACLE_BASE/admin/$ORACLE_SID/wallet/tde_seps'
     SCOPE=SPFILE;
SQL> SHUTDOWN IMMEDIATE
SQL> STARTUP

Next, add the keystore password (in this case S3cr3t) into SEPS as a secret for the client TDE_WALLET:

SQL> ADMINISTER KEY MANAGEMENT
     ADD SECRET 'S3cr3t' FOR CLIENT 'TDE_WALLET'
     USING TAG 'TDE keystore password'
     TO LOCAL AUTO_LOGIN KEYSTORE '$ORACLE_BASE/admin/$ORACLE_SID/wallet/tde_seps’;

Finally, replace the keystore password in your commands with SEPS using the EXTERNAL STORE clause:

SQL> --No longer need this
SQL> CREATE PLUGGABLE DATABASE ... KEYSTORE IDENTIFIED BY S3cr3t;
SQL> --Now you can do this
SQL> CREATE PLUGGABLE DATABASE ... KEYSTORE IDENTIFIED BY EXTERNAL STORE;

You can use KEYSTORE IDENTIFIED BY EXTERNAL STORE on most ADMINISTER KEY MANAGEMENT commands, like exporting and importing encryption keys, but for security reasons some ADMINISTER KEY MANAGEMENT commands still require that you type in the keystore password.

When you specify the location of SEPS, I strongly recommend that you stick to the default location, $ORACLE_BASE/admin/$ORACLE_SID/wallet/tde_seps. If you are also using WALLET_ROOT parameter, then SEPS must be stored in the default location.

If you are using Oracle Key Vault or a dedicated Hardware Security Module instead of a software keystore, you can store those credentials in SEPS as well. Respectively, use CLIENT set to OKV_PASSWORD or HSM_PASSWORD.

RAC

SEPS works fine on a RAC database as well.

  • For simplicity, I would place the SEPS keystore on shared storage. Then all nodes can access the same keystore.
  • When you create the keystore, do not use a local auto-login keystore. The keystore must be a regular auto-login keystore, if all nodes should be able to access it.
    ADMINISTER KEY MANAGEMENT ... TO AUTO_LOGIN KEYSTORE


Conclusion

You can simplify commands that involve the keystore by using SEPS. In addition, it will be more secure because you can avoid typing or hardcoding the keystore password in cleartext.

I have produced a small demo that you can watch on YouTube:

If you like the video and want more, remember to hit the subscribe button on our YouTube channel.

References

Upgrading in the cloud – VM DB Systems – What about downgrade?

In a previous blog post I showed how you could upgrade a 12.2 PDB by plugging it into a 19c CDB. But what about downgrade? Yeah, downgrade. You know, that really cool feature that you never practice, but you know you should.

In the previous blog post, I used the CDB that gets automatically created when you deploy a new 19c VM DB System and it comes with COMPATIBLE set to 19.0.0 – the default. When you provision a new VM DB System there is no way to control that parameter. Thus, when I plug in my old release PDB into the new release CDB the COMPATIBLE parameter is automatically raised, and I have lost the possibility of doing a downgrade. The only option to get back to the old release would be a Data Pump export.

If you want to preserve the possibility of doing a database downgrade, I strongly recommend you switch to Bare Metal DB Systems or ExaCS which are much more flexible. But if you insist on using VM DB Systems there is an option – it is cumbersome – but doable. And believe it or not – after working with Oracle Database for so many years it was the first time ever that I had to a downgrade – not even in a lab or a test environment (which became fairly obvious after I had asked for advice the 100th time that day).

Drop pre-created 19c database

To get a 19c CDB with a non-default COMPATIBLE setting we will drop the pre-created database and replace it with a backup that has the proper COMPATIBLE setting. This is supported and the same approach is used in the whitepaper “Hybrid Data Guard to Oracle Cloud Infrastructure”. It is a good read and it has a lot of script examples that I stole… oh… got inspired by.

Connect to the new release VM DB System and ensure that the environment variable ORACLE_UNQNAME is set to the DB_UNIQUE_NAME of the database:

echo $ORACLE_UNQNAME

If it is not set, you can get it from srvctl:

srvctl config database
export ORACLE_UNQNAME=...

Generate a script that can delete all data -, temp -, redo log – and control files:

SET HEADING OFF LINESIZE 999 PAGESIZE 999 FEEDBACK OFF TRIMSPOOL ON TIMING OFF
SPOOL /tmp/db_replace_files.lst
SELECT 'asmcmd rm '|| name FROM V$DATAFILE UNION ALL SELECT 'asmcmd rm '|| name FROM V$TEMPFILE UNION ALL SELECT 'asmcmd rm '|| member FROM V$LOGFILE UNION ALL SELECT 'asmcmd rm '|| name FROM V$CONTROLFILE;
SPOOL OFF
host chmod 777 /tmp/db_replace_files.lst

You must edit the script and get rid of the unneeded lines. Next, stop the database:

srvctl stop database -d $ORACLE_UNQNAME -o immediate

And log on as grid and delete the files using the script we just created:

. /tmp/db_replace_files.lst

As oracle, now restart the database instance in NOMOUNT mode (can’t really go further since we nuked the control files) and set the COMPATIBLE to the same setting as the old release CDB.

srvctl start database -db $ORACLE_UNQNAME -o NOMOUNT

sql / as sysdba
SQL> ALTER SYSTEM SET COMPATIBLE='12.2.0' SCOPE=SPFILE;
SQL> CREATE PFILE FROM SPFILE;

srvctl stop database -db $ORACLE_UNQNAME -o immediate
srvctl start database -db $ORACLE_UNQNAME -o nomount

sql / as sysdba
SQL> SHOW PARAMETER COMPATIBLE

Now we have a new release instance running with the old COMPATIBLE setting. Obviously, it is of no use – yet. Starting a 19c instance with a lower compatible setting

Create a backup of old release CDB

I will use the old release CDB as the source for my new release CDB and thus preserve my COMPATIBLE setting. Obviously, the old release CDB must be upgraded to the new release, so let us first must ensure that the source CDB can actually be upgraded. Use AutoUpgrade in ANALYZE and FIXUPS mode which is described in a previous blog post. We must execute the ANALYZE and FIXUPS mode on the source system because the target system will only be able to open the database in UPGRADE mode, and these steps must be executed while the database is running in normal mode.

Next, I will create a File Storage Service that I can use to share files between the two VM DB Systems. The File Storage Service is really nice because the transfer speed in and out of the service depends on the network bandwidth of your VM DB System. So, if you add more CPUs to the system, you get more network bandwidth to the service automatically. It is really easy to create a File Storage Service and it is very well documented, so I will skip that part here. After that you can mount the file system in your systems (as opc):

sudo mkdir -p /mnt/db-downgrade-122
sudo mount x.x.x.x:/db-downgrade-122 /mnt/db-downgrade-122
sudo chmod 777 /mnt/db-downgrade-122

I can now take a backup of the CDB and store it directly in my NFS mount point:

rman target /

RMAN> BACKUP DATABASE ROOT FORMAT '/mnt/db-downgrade-122/cdbroot_%U' PLUGGABLE DATABASE 'PDB$SEED' FORMAT '/mnt/db-downgrade-122/pdbseed_%U' PLUS ARCHIVELOG FORMAT '/mnt/db-downgrade-122/arch_%U';
RMAN> BACKUP CURRENT CONTROLFILE FORMAT '/mnt/db-downgrade-122/cf_%U';

Since the database is encrypted, we also need a copy of the keystore (or wallet). An easy solution could be to put the keystore files into the File Storage Service but a safer approach is to transfer the file directly using scp. Although, the keystore is protected by a password, it is still safer to keep them separated.

At time of writing, in OCI you can find the location of the keystore in sqlnet.ora.

cat $ORACLE_HOME/network/admin/sqlnet.ora | grep -i encryption_wallet

But that will change at some point in time because as of Oracle Database release 19c the sqlnet.ora parameter ENCRYPTION_WALLET_LOCATION is deprecated. You might have to look at the database parameter WALLET_ROOT instead.

For now, just note down the location of the keystore.

Restore old release CDB and upgrade

Now we can restore the backup of the 12.2 database using the 19c binaries. This is supported and in fact newer releases of RMAN can always restore lower release backups. However, normally RMAN will try to open the database in normal mode which we can’t do because of the version mismatch. I will use the NOOPEN keyword which causes RMAN to leave the database in MOUNT mode and I can manually open the database with RESETLOGS and in UPGRADE mode.

But first we must copy the keystore files from the source database to the new release DB System. In my example I am also copying the auto-login keystore which you shouldn’t do if you are using local auto-login keystores. In that situation the auto-login keystore should be re-created at the new release system:

cd
scp -i  oracle@:/cwallet.sso cwallet.sso
scp -i  oracle@:/ewallet.p12 ewallet.p12

Now let’s do the restore and open the database in upgrade mode:

rman auxiliary /

RMAN> DUPLICATE DATABASE TO CDB1 AS ENCRYPTED NOOPEN SKIP PLUGGABLE DATABASE SALES BACKUP LOCATION '/mnt/db-downgrade-122/';

And in the end, you can see that RMAN does not open the database: Using the NOPEN keyword you can prevent RMAN from opening a database at the end of the restore and recover operation

Then, you can open the database in UPGRADE mode and with RESETLOGS option to complete the restore. Also, drop the skipped pluggable databases from the data dictionary:

ALTER DATABASE OPEN RESETLOGS UPGRADE;
DROP PLUGGABLE DATABASE SALES INCLUDING DATAFILES;

Finally, you can use AutoUpgrade in UPGRADE mode to upgrade the CDB to the new release. You now have a new target system running on 19c but with a lower COMPATIBLE setting.

If you want to know more about the UPGRADE mode, have a look in the documentation.

Downgrading a PDB

Previously, we have laid the groundworks for the being able to do a downgrade. For the following, I am assuming that you have already upgraded your PDB to 19c and now you ended up in a big doo doo and have to downgrade.

Downgrading in VM DB Systems are also slightly more complicated than on other systems. Remember that VM DB Systems does only support one Oracle Home (the one that comes deployed automatically) and that means that we must move the database back to the source system. For that operation we can’t use data guard, RMAN, or any other fancy approach because they only work to the same or newer release. So, we will have to do an old-school cold copy of the database – and that requires additional downtime. But let’s get started!

I will create a file that gives me all the commands I need to copy the data files out of ASM and into my File Storage Service (you could also scp them directly to the old release system):

SET HEADING OFF LINESIZE 999 PAGESIZE 999 FEEDBACK OFF TRIMSPOOL ON TIMING OFF
SPOOL /tmp/db_downgrade_files.lst
SELECT 'asmcmd cp ' || name || ' ''/mnt/dbbackupstaging' || SUBSTR(name, INSTR(name, '/', -1 )) || '''' FROM V$DATAFILE
UNION
SELECT 'chown oracle:oinstall /mnt/dbbackupstaging' || SUBSTR(name, INSTR(name, '/', -1 )) FROM V$DATAFILE ORDER BY 1;
SPOOL OFF

And then I can proceed with the actual downgrade. I need to ensure that the unified audit trail is emptied before the downgrade:

ALTER PLUGGABLE DATABASE SALES CLOSE;
ALTER PLUGGABLE DATABASE SALES OPEN DOWNGRADE;
EXEC DBMS_AUDIT_MGMT.CLEAN_AUDIT_TRAIL(DBMS_AUDIT_MGMT.AUDIT_TRAIL_UNIFIED, FALSE);
SPOOL /tmp/db_downgrade.lst
SET TERMOUT ON TIMING ON SERVEROUT ON ECHO ON
@?/rdbms/admin/catdwgrd.sql
SPOOL OFF

Unplug the PDB and because the PDB is encrypted I have to specify a password that can protect the sensitive information inside the manifest file:

ALTER SESSION SET CONTAINER=CDB$ROOT;
ALTER PLUGGABLE DATABASE SALES CLOSE;
ALTER PLUGGABLE DATABASE SALES UNPLUG INTO '/mnt/db-downgrade-122/manifest_sales.xml' ENCRYPT USING [a-secret-password];

Now we can copy the data files from the local storage and on to the File Storage Service so we can use at the source system. Use the commands that we generated previously:

asmcmd ...
chown ...

Now switching to the old release system and create the PDB from manifest file. I will use the data files right off the File Storage Service and optionally I can move them afterwards – as an online operation (you might not want to do that, but I ran out of disk space):

CREATE PLUGGABLE DATABASE SALES USING '/mnt/db-downgrade-122/manifest_sales.xml' SOURCE_FILE_DIRECTORY='/mnt/db-downgrade-122' NOCOPY KEYSTORE IDENTIFIED BY [keystore-password] DECRYPT USING [a-secret-password];

Start up the database in UPGRADE mode and open the keystore:

ALTER PLUGGABLE DATABASE SALES OPEN UPGRADE;
ADMINISTER KEY MANAGEMENT SET KEYSTORE CLOSE CONTAINER=all;
ADMINISTER KEY MANAGEMENT SET KEYSTORE OPEN IDENTIFIED BY [keystore-password] CONTAINER=all;

Switch to the SALES PDB and complete the downgrade:

ALTER SESSION SET CONTAINER=SALES;
SET TERMOUT ON ECHO ON TIMING ON
SPOOL /home/oracle/sales_catreload.log
@?/rdbms/admin/catrelod.sql
SPOOL OFF

Restart, Recompile and fresh stats:

ALTER PLUGGABLE DATABASE SALES CLOSE IMMEDIATE;
ALTER PLUGGABLE DATABASE SALES OPEN;
@?/rdbms/admin/utlrp.sql
EXEC DBMS_STATS.GATHER_DICTIONARY_STATS;
EXEC DBMS_STATS.GATHER_FIXED_OBJECT_STATS;

Check the state of the Oracle Data Dictionary

SET SQLFORMAT ANSICONSOLE LINES 300
SELECT COMP_ID, COMP_NAME, VERSION, STATUS FROM DBA_REGISTRY ORDER BY MODIFIED;

And there you have it. Not exactly super easy, which is why I highly recommend you to look at Bare Metal DB Systems or Exadata DB Systems if you are required to be able to do downgrades (or be prepared to use Data Pump instead).

Other Posts in This Series
