Patching Oracle Grid Infrastructure 19c – Beginner’s Guide

This is the start of a blog post series on patching Oracle Grid Infrastructure 19c (GI). It is supposed to be easy to follow, so that I may have skipped a detail here and there.

I know my way around database patching. I have done it countless times. When it comes to GI, it’s the other way around. I have never really done it in the real world (i.e., before joining Oracle) and my knowledge was limited. I told my boss, Mike, and he gave me a challenge: Learn about it by writing a blog post series.

Why Do I Need to Patch Oracle Grid Infrastructure

Like any other piece of software, you need to patch GI to get rid of security issues and fix issues.

You should keep the GI and Oracle Database patch level in sync. This means that you need to patch GI and your Oracle Database at the same cadence. Ideally, that cadence is quarterly.

It is supported to run GI and Oracle Database at different patch levels as long as they are on the same release. GI is also certified to run some of the older Oracle Database releases. This is useful in upgrade projects. Check Oracle Clusterware (CRS/GI) – ASM – Database Version Compatibility (Doc ID 337737.1) for details.

A few examples:

GI Database Supported
19.18.0 19.18.0 Yes – recommended
19.16.0 19.18.0 Yes
19.18.0 19.16.0 Yes
19.18.0 11.2.0.4 Yes – used during upgrade, for instance
19.18.0 21.9.0 No

If possible and not too cumbersome, I recommend that you first patch GI and then Oracle Database. Some prefer to patch the two components in two separate operations, while others do it in one operation.

Which Patches Should You Apply to Oracle Grid Infrastructure

You should apply:

Whether you download the bundle patches individually or go with the combo patch is a matter of personal preference. Ultimately, they contain the same.

Some prefer an N-1 approach: When the April Release Update comes, they patch with the previous one from January; Always one quarter behind. For stability reasons, I assume.

What about OJVM patches for GI? The short answer is no.

Which Method Do I Use For Patching

You can patch in two ways:

  • In-place patching
  • Out-of-place patching
In-place Out-of-place
You apply patches to an existing Grid Home. You apply patches to a new Grid Home.
You need disk space for the patches. You need disk space for a brand new Grid Home and the patches.
You patch the existing Grid Home. When you start patching a node, GI drains all connections and moves services to other nodes. The node is down during patching. You create and patch a new Grid Home without downtime. You complete patching by switching to the new Grid Home. The node is down only during switching.
Longer node downtime. Shorter node downtime.
No changes to profile and scripts. Profile, scripts and the like must be updated to reflect the new Grid Home.
My recommended method.

Note: When I write node downtime, it does not mean database downtime. I discuss it shortly.

In other words:

In-place patching replaces the Oracle Clusterware software with the newer version in the same Grid home. Out-of-place upgrade has both versions of the same software present on the nodes at the same time, in different Grid homes, but only one version is active.

Oracle Fleet Patching and Provisioning

When you have more systems to manage, it is time to consider Fleet Patching and Provisioning (FPP).

Oracle Fleet Patching & Provisioning is the recommended solution for performing lifecycle operations (provisioning, patching & upgrades) across entire Oracle Grid Infrastructure and Oracle RAC Database fleets and the default solution used for Oracle Database Cloud services

It will make your life so much easier; more about that in a later blog post.

Zero Downtime Oracle Grid Infrastructure Patching

As of 19.16.0 you can also do Zero Downtime Oracle Grid Infrastructure Patching (ZDOGIP).

Use the zero-downtime Oracle Grid Infrastructure patching method to keep your Oracle RAC database instances running and client connections active during patching.

ZDOGIP is an extension to out-of-place patching. But ZDGIOP will not update the operating system drivers and will not bring down the Oracle stack (database instance, listener etc.). The new GI takes over control of the Oracle stack without users noticing. However, you must update the operating system drivers by taking down the node. But you can postpone it to a later point in time.

More details about ZDGIOP in a later blog post.

What about Oracle Database Downtime

When you patch GI on a node, the node is down. You don’t need to restart the operating system itself, but you do shut down the entire GI stack, including everything GI manages (database, listeners etc.).

What does that mean for Oracle Database?

Single Instance

If you have a single instance database managed by GI, your database is down during patching. Your users will experience downtime. By using out-of-place patching, you can reduce downtime.

Data Guard

If you have a Data Guard configuration, you can hide the outage from the end users.

First, you patch GI on your standby databases, then perform a switchover, and finally patch GI on the former primary database.

The only interruption is the switchover; a brownout period while the database switches roles. In the brownout period, the database appears to hang, but underneath the hood, you wait for the role switch to complete and connect to the new primary database.

If you have configured your application properly, it will not encounter any ORA-errors. Your users experience a short hang and continue as if nothing had happened.

RAC

If you have a RAC database, you can perform the patching in a rolling manner – node by node.

When you take down a node for patching, GI tells connections to drain from the affected instances and connect to other nodes.

If your application is properly configured, it will react to the drain events and connect seamlessly to another instance. The end users will not experience any interruption nor receive any errors.

If you haven’t configured your application properly or your application doesn’t react in due time, the connections will be forcefully terminated. How that will affect your users depend on the application. But it won’t look pretty.

Unless you configure Application Continuity. If so, the database can replay any in-flight transaction. From a user perspective, all looks fine. They won’t even notice that they have connected to a new instance and that the database replayed their transaction.

Happy Patching!

Appendix

Other Blog Posts in This Series

Further Reading

Installing Oracle Database 19c and All the Things to Put on Top

When you prepare for patching or upgrading Oracle Database 19c, you must also prepare an Oracle Home. Installing the Oracle Home is easy, but there is more to it.

Out-of-place Installation

I always use out-of-place installation. I install a new, fresh Oracle Home. I will move the databases into that Oracle Home as I upgrade or patch.

The alternative, in-place installation, leads to more downtime, is more error-prone, and makes fallback more complicated. In addition, in-place installation will gradually slow down patching; as Mike Dietrich describes in Binary patching is slow because of the inventory.

Download and Prepare Oracle Home

First, I download the base release from Oracle Software Delivery Cloud, aka e-delivery.

Find REL: Oracle Database 19.3.0.0.0 – Long Term Release, the right platform, and download.

Extract the zip file into a new Oracle Home location:

export NEW_ORACLE_HOME=<path>
mkdir -p $NEW_ORACLE_HOME
cd $NEW_ORACLE_HOME
unzip -oq /tmp/LINUX.X64_193000_db_home.zip
rm /tmp/LINUX.X64_193000_db_home.zip

Don’t run the installer yet.

Clone Existing Oracle Home

I could clone an existing Oracle Home and then just apply the new patches. But it will make me susceptible to the same issue described above about in-place patching. Plus, if you clone an Oracle Home with one-offs then you might need to roll them off before you can apply the next Release Update.

Update OPatch

OPatch is needed later on to apply patches to the new Oracle Home. Get the latest version and install it into the new Oracle Home:

rm -rf $NEW_ORACLE_HOME/OPatch
cd $NEW_ORACLE_HOME
unzip -oq /tmp/<opatch_zip_file>
rm /tmp/<opatch_zip_file>

Patches

Now, I will determine which patches to apply to the Oracle Home.

  • Start by getting the latest Release Update. I really mean the latest. I have helped too many customers with issues, only to find out the issue is already solved in a later Release Update. If your database has JAVAVM installed, then get the combo patch.
  • Review the list of important one-off patches for the specific Release Update. The list contains important fixes that haven’t made into a Release Update yet. I don’t need to get all of them, but based on my knowledge of my database, I can cherrypick those that could be relevant.
  • If I am using Data Pump, I get the Data Pump bundle patch. Data Pump fixes rarely make it into Release Updates, because they are not RAC-Rolling Installable which is a clear requirement for inclusion in Release Update.
  • If I am using GoldenGate, I get the GoldenGate bundle patch.
  • If my database uses OJVM (see appendix), I get the OJVM patch that matches the Release Update I am using. I can also get the OJVM patch as a combo patch together with the Release Update.

Unzip

Now that I have downloaded a number of zip files, I go ahead and unzip the files into separate directories. In the below example, I am using 19.16 Release Update and Data Pump bundle patch:

#Release Update 19.16.0
mkdir -p $NEW_ORACLE_HOME/patch/p34133642
cd $NEW_ORACLE_HOME/patch/p34133642
unzip -oq /tmp/p34133642_190000_Linux-x86-64.zip
rm /tmp/p34133642_190000_Linux-x86-64.zip

#Data Pump bundle patch
mkdir -p $NEW_ORACLE_HOME/patch/p34294932
cd $NEW_ORACLE_HOME/patch/p34294932
unzip -oq /tmp/p34294932_1916000DBRU_Generic
rm /tmp/p34294932_1916000DBRU_Generic

Install

Now, I can install the Oracle Home and apply all the patches in one operation. Mike has a really good description of the functionality and a demo.

I do a silent installation using a response file. Notice how I am applying the patches during the installation using -applyRU and -applyOneOffs:

export ORACLE_BASE=<path_to_oracle_base>
export ORACLE_HOME=<path_to_oracle_home>
#Path to inventory is most likely /u01/app/oraInventory
export ORA_INVENTORY=<path_to_inventory>
cd $ORACLE_HOME
./runInstaller -ignorePrereqFailure -waitforcompletion -silent \
   -responseFile $ORACLE_HOME/install/response/db_install.rsp \
   -applyRU patch/p34133642/34133642 \
   -applyOneOffs patch/p34294932/34294932 \
   oracle.install.option=INSTALL_DB_SWONLY \
   UNIX_GROUP_NAME=oinstall \
   INVENTORY_LOCATION=$ORA_INVENTORY \
   SELECTED_LANGUAGES=en,en_GB \
   ORACLE_HOME=$ORACLE_HOME \
   ORACLE_BASE=$ORACLE_BASE \
   oracle.install.db.InstallEdition=EE \
   oracle.install.db.OSDBA_GROUP=dba \
   oracle.install.db.OSBACKUPDBA_GROUP=dba \
   oracle.install.db.OSDGDBA_GROUP=dba \
   oracle.install.db.OSKMDBA_GROUP=dba \
   oracle.install.db.OSRACDBA_GROUP=dba \
   oracle.install.db.isRACOneInstall=false \
   oracle.install.db.rac.serverpoolCardinality=0 \
   oracle.install.db.config.starterdb.type=GENERAL_PURPOSE \
   oracle.install.db.ConfigureAsContainerDB=false \
   SECURITY_UPDATES_VIA_MYORACLESUPPORT=false \
   DECLINE_SECURITY_UPDATES=true

You can read more about silent installation on oracle-base.com. That’s where I got inspired from. The reponse file db_install.rsp is the default one that comes with the Oracle Home. I don’t change anything in it.

Finally, I execute root.sh as root:

$ORACLE_HOME/root.sh

AutoUpgrade

Download the latest version of AutoUpgrade, and put it into $ORACLE_HOME/rdbms/admin.

Et Voilà

That’s it. I can now use the Oracle Home to upgrade or patch my Oracle Database 19c.

When you move your Oracle Database to the new Oracle Home, be sure to move all the necessary configuration files as well.

Appendix

Patches

As if the list of patches to apply wasn’t long enough. There are even more MOS notes!

Good news is that you don’t have to go through them, as long as you stay on the latest Release Update. If you check the notes, you will see that almost all bugs are already included in a Release Update. That’s a pretty strong argument for always using the latest Release Update.

  • Things to Consider to Avoid Prominent Wrong Result Problems on 19C Proactively (Doc ID 2606585.1)
  • Things to Consider to Avoid Database Performance Problems on 19c (Doc ID 2773012.1)
  • Things to Consider to Avoid SQL Performance Problems on 19c (Doc ID 2773715.1)
  • Things to Consider to Avoid SQL Plan Management (SPM) Related Problems on 19c (Doc ID 2774029.1)

Grid Infrastructure

If Grid Infrastructure manages my database, I must remember to keep GI and database patch level in sync.

It Looks Complicated

It is a little to cumbersome. We know, and that’s why there are several initiatives to make it easier.

You could also look at Oracle Fleet Patching & Provisioning (FPP). Philippe Fierens is product manager for FPP. You can read his blog posts or reach out to him (he is a nice guy who takes every opportunity to talk about FPP).

OJVM

If your database is using OJVM, then you must also apply the OJVM patch to your Oracle Home. You can check it using:

select version, status from dba_registry where comp_id=’JAVAVM’

I have seen many databases that had OJVM installed, but it was never used. In such case, you can remove the component from your database. Then you no longer need to apply the OJVM patch to your Oracle Home. Plus it has the added benefit that it will make your upgrades faster.

Mike Dietrich has a good blog – the OJVM Patching Saga. Catchy title!
