If Importing Statistics Using DBMS_STATS Is Slow

When migrating Oracle Databases, you often transport the statistics using dbms_stats. Our team got involved in an interesting case the other day, and I would like to share the solution with you.

Problem

A customer migrated to Oracle Database 19c and decided to move the statistics using dbms_stats.import_schema_stats. They noticed that the procedure started to burn a lot of CPU, and after 38 hours, they gave up.

A SQL Monitor report showed one statement which spent almost all the time. An insert statement into sys.dbms_stats_id_map_tab with a subselect referencing the staging table. The staging table is the one you specify in the argument stattab in the call to dbms_stats.import_schema_stats. The staging holds the optimizer statistics in a portable format. From the staging table, the procedure can insert it into the data dictionary in the proper format.

Obviously, they could see already that the procedure would use far too much time.

Diagnosing

The first shot was to look at the code behind dbms_stats. But this specific code hadn’t changed since its introduction many releases ago.

Recursive statements that touch the data dictionary immediately brought our attention to dictionary statistics. But the customer told us that they were not stale.

The customer ran SQL Tuning Advisor on the offending statement, and one of the findings was about stale statistics. SQL Tuning Advisor recommended gathering statistics on the staging table and corresponding indexes.

One of our performance experts looked at the execution plan and found a pattern he had seen before. He tried to disable Join Predicate Push Down in the session. It helped, but this was just a workaround. We wanted to find the root cause.

Solution

The SQL Tuning advisor came up with the real problem. Stale statistics on the staging table and corresponding indexes. Once the customer gathered statistics on the staging table and indexes, the import of statistics finished in 2 hours and 27 minutes which was acceptable.

We also discovered that the dictionary statistics were not as accurate as the customer had initially concluded. In fact, by mistake, they had misinformed us. A fresh run of dbms_stats.gather_dictionary_stats gave a slight performance improvement as well.

Recommendations

These recommendations are now part of our best practices for migrations.

  1. Before importing statistics using dbms_stats.import_schema_stats, gather stats on the staging table.

  2. Immediately after importing a lot of data, and before you import statistics with dbms_stats or anything else, you should gather dictionary statistics. This applies to regular Data Pump imports and transportable tablespace metadata imports.

The run book should look like this:

$ impdp parfile=import.par ...
$ sqlplus / as sysdba

SQL> exec dbms_stats.gather_dictionary_stats;
SQL> exec dbms_stats.gather_table_stats(
		ownname=>'SYSTEM',
		tabname=>'MY_STG_TAB_1',
		cascade=>TRUE);
SQL> exec dbms_stats.import_schema_stats(
		ownname=>'SYSTEM',
		stattab=>'MY_STG_TAB_1',

In the above example, the staging table is called SYSTEM.MY_STG_TAB_1.

The recommendation applies as well if you are using the procedures dbms_stats.import_database_stats or dbms_stats.import_table_stats.

Dictionary Statistics

Why is it important to gather dictionary statistics immediately after the import?

When you import data or use transportable tablespaces, you often have a brand new, empty database. Then you import a lot of objects. Those objects are represented as rows in the data dictionary. For instance, the tables you import now appear as rows in SYS.TAB$, the partitions in SYS.TABPART$, the indexes in SYS.IND$, and so forth.
Those internal tables were almost empty before – there were not a lot of tables. Now they have a lot of rows. This means that the statistics are stale. When you start to use functionality in the database, like importing statistics, recursive queries using the internal tables will be executed. With stale statistics on the dictionary, you can have suboptimal execution plans and bad performance. Gathering dictionary statistics can fix this for you.

Conclusion

Statistics are always vital, whether optimizer statistics on user data or internally in the data dictionary. Be sure to verify the accuracy of your statistics when you have problems.

Also, SQL Tuning Advisor is a great tool. It can quickly come up with suggestions for fixing problems. Use the recommendations as input to your troubleshooting. SQL Tuning Advisor also works on internal tables.

Additional Information

We have a few videos on our YouTube channel which have more information about transporting statistics with dbms_stats.

XTTS: Prerequisites

When migrating Oracle Database to a different endian format using transportable tablespaces and incremental backups (XTTS), a list of requirements must be met. The following list of requirements exist when using:

V4 Perl Script

The most important requirements – for a complete list check MOS note:

  • Windows is not supported.
  • RMAN on the source system must not have DEVICE TYPE DISK configured to COMPRESSED.
  • RMAN on the source system must not have default channel configured to type SBT.
  • For Linux: Minimum version for source and destination is 11.2.0.3.
  • Other platforms: Minimum version for source and destination is 12.1.0.2.
  • Disk space for a complete backup of the database on both source and target host. If your data files take up 100 TB, you need an additional 100 TB of free disk space. For 12c databases, and if your data files have a lot of free space, the backup might be smaller due to RMAN unused block compression.

Also worth mentioning is that the Perl script during the roll forward phase (applying level 1 incremental) will need to restart the target database. Applying the incremental backups on the target data files happens in NOMOUNT mode. Be sure nothing else uses the target database while you roll forward.

Block Change Tracking (BCT) is strongly recommended on the source database. Note, that this is an Enterprise Edition feature (in OCI: DBCS EE-EP or ExaCS). If you don’t enable BCT the incremental backups will be much slower because RMAN has to scan every single data block for changes. With BCT the database keeps track of changes in a special file. When RMAN backs up the database, it will just get a list of data blocks to include from the change tracking file.

What If – V3 Perl Script

If disk space is a problem or if you can’t meet any of the other requirements, check out the below two MOS notes:

They describe a previous version of the Perl script, version 3. The scripts use DBMS_FILE_TRANSFER to perform the conversion of the data files in-flight. That way no extra disk space is needed. However, DBMS_FILE_TRANSFER has a limitation that data files can’t be bigger than 2 TB.

Also, the V3 scripts might be useful for very old databases.

Transportable Tablespaces In General

To get a complete list of limitations on transporting data, you should look in the documentation. The most notable are:

  • Source and target database must have compatible character sets. If the character sets in both databases are not the same, check documentation for details.
  • No columns can be encrypted with TDE Column Encryption. The only option is to remove the encryption before migration and re-encrypt afterward.
  • TDE Tablespace Encryption is supported for same-endian migration if the source database is 12.1.0.2 or newer. If you need to go across endianness, you must decrypt the tablespaces and re-encrypt after migration. Remember, Oracle Database 12.2 can encrypt tablespaces online.
  • If you are migrating across endianness, you must convert the data files. You must have disk space to hold a copy of all the data files. In addition, you should perform the conversion on the platform that has the best I/O system and most CPUs. Typically, this is the cloud platform, which also offers scaling possibilities.
  • Requires Enterprise Edition.
  • The database timezone file version in the target database must be equal to or higher than the source database.
  • The database time zone must match if you have tables with TIMESTAMP WITH LOCAL TIME ZONE (TSLTZ). If you have such tables, and the database time zone does not match, those tables are skipped during import. You can then move the affected tables using a normal Data Pump table mode export and import. To check the database time zone:
    SQL> select dbtimezone from dual;

    You can alter the time zone for a database with an ALTER DATABASE statement.

Full Transportable Export/Import

FTEX automates the process of importing the metadata. It is simpler to use and automatically includes all the metadata in your database. Compared to a traditional transportable tablespace import, FTEX is a lot easier and removes a lot of manual work from the end user. But there are a few requirements that must be met:

  • Source database must be 11.2.0.3 or higher.
  • Target database must be 12.1.0.1 or higher.
  • Requires Enterprise Edition.
  • COMPATIBLE must be set to 12.0.0 or higher in both source and target database. If your source database is an Oracle Database 11g, this is not possible. In that case, set version to 12 or higher during Data Pump export instead.

If you can’t meet the requirements, check out traditional transportable tablespace. It have different requirements, and it allows more customization.

Other Blog Posts in This Series

XTTS: ASM Aliases and Why You Should Get Rid of Them

If you migrate an Oracle Database using cross-platform transportable tablespaces (XTTS) and incremental backups and if your target database use ASM, you should get rid of the aliases after the migration.

What Is an ASM Alias?

When you use ASM, there is tight control over the file names. ASM strictly enforces the naming standard dictated by Oracle Managed Files (OMF), and only the database can create file names that comply with OMF.

Sometimes it is handy to create files in other locations in ASM that still refer to a database file. Here you can use aliases. Aliases work like a symbolic link in the file system.

How can you tell if a file is an alias?

Alias Oracle ASM file names are distinguished from fully qualified file names or numeric file names because they do not end in a dotted pair of numbers. It is an error to attempt to create an alias that ends in a dotted pair of numbers, such as in the format USERS.259.685366091.

When you use ls -l you can also tell whether a file is an alias. The column SYS (System-generated) is N, meaning this is not a proper OMF file. Also, you can see in the Name column that it is an alias. The => indicate it:

ASMCMD> ls -l +DATA
Type      Redund  Striped  Time             Sys  Name
DATAFILE  UNPROT  COARSE   MAR 16 08:00:00  N    account_25.dbf => +DATA/CDB1_FRA2KR/86D5DC2587337002E0532AB2A8C0A57C/DATAFILE/ACCOUNT.282.1099469855
DATAFILE  UNPROT  COARSE   MAR 16 08:00:00  N    accountidx_26.dbf => +DATA/CDB1_FRA2KR/86D5DC2587337002E0532AB2A8C0A57C/DATAFILE/ACCOUNTIDX.280.1099469855

You can read about Fully Qualified File Name Form in the ASM documentation, if you are interested.

Why Are the Aliases Created?

When the Perl script is restoring and recovering the data files on the target database, they do not belong to any database yet. The tablespaces have not been plugged into any database yet. Hence, it is impossible to figure out the right OMF name of the data files. As an alternative, ASM names the data files according to the syntax of the source database. For instance, it will use the source database GUID (select guid from v$containers) as part of the name. In addition, the Perl script creates ASM aliases using the following format: <dest_datafile_location>/<tablespace_name>_<file#>.dbf

When you perform the Data Pump import, you can refer to the aliases in your Data Pump parameter file (transport_datafile). Using the aliases is especially useful if you plan on having a standby database.

How Do I Get Rid of the Aliases?

After performing the Data Pump import, the tablespaces are plugged into a database, and now the data files belong to a database. But the target database is referring to the data files either via:

  • An ASM alias
  • Or directly via the absolute file name. As described earlier, the absolute file path uses the OMF syntax of the source database

Let me illustrate that. Imagine:

  • In xtt.properties dest_datafile_location=+DATA.
  • My data file is named users01.dbf, belongs to tablespace USERS and has file ID 65.
  • Target DB_UNIQUE_NAME is SALES2.
  • Source database GUID is 86D5DC2587337002E0532AB2A8C0A57C.

How will the file be registered in the database?

  • If I used the aliases, it is known as +DATA/users_65.dbf.
  • If I used the absolute file name, it is known as +DATA/SALES2/86D5DC2587337002E0532AB2A8C0A57C/DATAFILE/users.280.1099469855. ASM generates the last two sets of numbers.

Neither of the two formats is proper OMF names. What is the real OMF name? Imagine:

  • Target database GUID is DA495482D68D0220E0530F01000A98DF
  • The real OMF file name is (notice the change in GUID): +DATA/SALES2/DA495482D68D0220E0530F01000A98DF/DATAFILE/users.280.1099469855

You can get the GUID of a database by using select guid from v$containers.

In ASM, only the database can store a file in OMF syntax. You must fix this from the target database. The easiest way is to use online data file move. If you don’t specify the target location, the database will generate an OMF name:

SQL> --using file number
SQL> alter database move datafile 65;
SQL> --using full name
SQL> alter database move datafile '+DATA/users_65.dbf';

How does the move work?

  • It is a entirely online operation.
  • It is a block-by-block copy.
  • The database copies the data file. While the copy operation takes place, the two files are kept in sync until the database can switch to the new file. After that, the database removes the original file.
  • If the data file belongs to a PDB, you must switch your session to that container.

You can learn more about online data file move in our YouTube video:

Why Bother?

If my database works fine, why should I worry? I can think of at least two reasons:

  • Comply to naming standard
  • Avoid problems in other migrations

Comply to naming standard

I highly recommend that you use and comply with any naming standard, including OMF. Data files that are not appropriately stored according to OMF, should be moved to the correct location.

When I worked outside in the real world as a DBA, I remember multiple occasions of loss of data files. In many situations, a DBA had found a file apparently not belonging to a database – at least according to the naming standard. But the file was used by a database; it was just not stored in the correct location. When the file was removed = big problem in the database.

With many databases and many hosts, it is very important that you make standards and keep with the standards. Otherwise, you will end up in a big mess.

Avoid problems in other migrations

This is especially relevant if you need to perform multiple migrations to the same database host.

The Perl script used for the migration will create the aliases in the location specified by dest_datafile_location. The names of the aliases are very simple, and there is a risk that another migration will try to make the same alias.

Imagine you already did one migration. The database uses the alias +DATA/users_4.dbf. Now you want to make a second migration, and this database also wants to use +DATA/users_4.dbf. The same alias can’t be used for two different files. Big problem!

A user left a comment on my blog telling me this actually lead to corruption in the first database. That risk is a very good reason for getting rid of the aliases and using only proper OMF file names.

Conclusion

ASM aliases are created automatically as part of the migration. The aliases are very useful during the migration, but I highly recommend getting rid of the aliases right after the migration.

Other Blog Posts in This Series

XTTS: Backup on Standby Database

When doing a cross-platform migration with transportable tablespaces and incremental backup, is it possible to perform backups on a standby database? If so, you could offload the work from a primary database.

The short answer is yes. You can use a physical standby database but not a snapshot standby database.

Using a standby database for the backups is an advantage in some situations:

  • The primary database does not have the capacity to perform the extra backups (CPU, disk space, or I/O).
  • You want the primary database to be completely unaffected by the migration.

How To

You follow the regular procedure described in the MOS note V4 Reduce Transportable Tablespace Downtime using Cross Platform Incremental Backup (Doc ID 2471245.1) with a few changes. The changes are described in Using XTTs in a Data Guard Environment.

Be Careful

You must have an Active Data Guard license, if you:

  • Open a physical standby database and enable redo apply.
  • Enable block change tracking on the standby database (for faster incremental backups).

Procedure

The primary database is called SRCPRI and runs on the host src-pri. The standby is called SRCSTDBY and runs on the host src-stdby.

  • Ensure allowstandby=1 in xtt.properties.

  • Whenever you need to perform a backup on the physical standby database – level 0 or incremental:

    • Cancel redo apply and open the physical standby database:
    SRCSTDBY SQL> alter database recover managed standby database cancel;
    SRCSTDBY SQL> alter database open;

    • Perform the backup
    [oracle@src-stdby]$ $ORACLE_HOME/perl/bin/perl xttdriver.pl --backup

    • Bring the standby database back in MOUNT mode and re-enable redo apply:
    SRCSTDBY SQL> shutdown immediate
    SRCSTDBY SQL> startup mount
    SRCSTDBY SQL> alter database recover managed standby database disconnect from session;

  • When it is time to perform the final incremental backup:

    • Set tablespaces in READ ONLY mode on the primary database:
    SRCPRI SQL> alter tablespace ... read only;

    • Archive current log and ensure it is applied on the standby database:
    SRCPRI SQL> alter system archive log current;

    • When you have confirmed the redo is applied on the standby database, cancel redo apply and open it:
    SRCSTDBY SQL> alter database recover managed standby database cancel;
    SRCSTDBY SQL> alter database open;

    • Verify tablespaces are READ ONLY:
    SRCSTDBY SQL> select tablespace_name, status from dba_tablespaces;

    • Perform the final incremental backup
    [oracle@src-stdby]$ $ORACLE_HOME/perl/bin/perl xttdriver.pl --backup

    • Perform the Data Pump export on the primary database:
    [oracle@src-pri]$ expdp system ... full=y transportable=always ...


Active Data Guard

If you have a license for Active Data Guard, you can simply keep the physical standby database in OPEN WITH REDO APPLY mode. You don’t need to switch from OPEN mode to MOUNT mode.

Conclusion

Being able to perform the backups on a standby database is a huge advantage. But it makes the process slightly more complicated, so I would recommend it only if really needed. In addition, if you don’t follow the procedure strictly, you might accidentally use a feature that requires Active Data Guard.

The MOS note V4 Reduce Transportable Tablespace Downtime using Cross Platform Incremental Backup (Doc ID 2471245.1) has some additional details about using a standby database. You can get those details by opening a Service Request and asking for it.

Other Blog Posts in This Series

XTTS: Slow Network Between Source and Target

When you migrate an Oracle Database using cross-platform transportable tablespaces (XTTS) and incremental backups, you will need to transfer a large amount of data to the target host. In some situations, especially if the target host is in a remote data center or the cloud, you are restricted by the network throughput, and it can be a limiting factor.

One approach to speed up the data transfer is to compress it before it leaves the source host. Compressing and decompressing takes time and CPU. But if your network connection is slow enough, it may pay off in the end.

The Approach

Like all other posts in this series, I am using the Perl scripts found in MOS note V4 PERL Scripts to reduce Transportable Tablespace Downtime using Cross Platform Incremental Backup.

First, you start the initial level 0 backup of the source database:

$ORACLE_HOME/perl/bin/perl xttdriver.pl --backup

The backups will be stored in the directory defined by src_scratch_location. In my case, the directory is /u01/app/oracle/xtts_src_scratch. Now you can simple compress the entire directory:

gzip -r /u01/app/oracle/xtts_src_scratch

This should significantly reduce the size of the files. Transfer the compressed files to your target host, and put them into the directory defined by dest_scratch_location. Then, uncompress the files:

gunzip -r /u01/app/oracle/xtts_dest_scratch

Continue the procedure described in the above MOS note and start the restore:

$ORACLE_HOME/perl/bin/perl xttdriver.pl --restore

Some Figures

I made a little test to give you an idea of how much there is to save.

Size
Data files total size 197 GB
Backup set size 197 GB
After gzip compression 12 GB

Because I don’t have any free space in my data files, the backup sets have almost the same size as the actual data files – 197 GB. By gzipping the files I could reduce the file size to 12 GB. So there is a significant amount to save – from 197 GB to 12 GB. It makes a huge difference whether you have to transfer 197 or 12 GB. But you must consider the time it takes to compress and decompress.

Elapsed time
Compression 13 min 52 sec
Decompression 8 min 7 sec

I made the same test but with image file backups and the numbers were almost the same. Generally, you should always try to use backup sets over image file backups. Backup sets use unused block compression which will skip all the unused blocks in your data files. That can make quite a difference for database with a lot of free space.

What About RMAN Compression

RMAN does have the option of compressing the backup set, but that is currently not supported by the Perl scripts. If the Perl scripts would be able to do that, you could get a good compression ratio with RMAN compression as well (of course provided you have a license for Advanced Compression Option) and avoid the gzip trick. Using the example above, by using RMAN compressed backup sets (medium compression) the backup files would be 0,3 GB which is very good as well.

But for now, you are "stuck" with the gzip trick.

Final Words

A few things to consider:

  • You should only consider this approach if you have a slow network.
  • You will need extra disk space during the compression/decompression operation.
  • You should only compress the initial, level 0 backup. The subsequent level 1 incremental backups will be much smaller in size, and it is unlikely to pay off.
  • You should test on your own database and hardware to know the actual compression ratio. Add the network throughput to the equation, and you can do the math to see if it is a good idea for your specific project.

Other Blog Posts in This Series

Oracle Database 21c Is Here

Last week Oracle released Oracle Database 21c for additional platforms: Linux and Exadata. Other platforms will follow. You should keep an eye out for Release Schedule of Current Database Releases (Doc ID 742060.1) for further information.

Things to Notice

In my part of the Oracle Database, there are things to notice. I want to highlight:

To get all the details, visit the Upgrade and Utilities part of the new features documentation. There are some good examples of how the features can be used.

Behaviour Changes

Read-Only Oracle Home (ROOH) is now the default. Be sure to set the following environment variables to control the location of these directories:

  • ORACLE_BASE_HOME
  • ORACLE_BASE_CONFIG

I like ROOH, but it takes some time to get used to. For instance, network/admin files (tnsnames, sqlnet) and dbs files (pfile, spfile) are now in a new location.

The Pre-Upgrade Information Tool or preupgrade.jar is removed and replaced by AutoUpgrade. A few new parameters have been introduced to make the transition easier.

Innovation Release

Remember, 21c is an innovation release, which means a shorter support window than Long Term Releases such as Oracle Database 19c. If you adopt Innovation Releases, you should be prepared to upgrade to the next database release within one year after the next database release ships.

I would not recommend that you upgrade your production systems to Oracle Database 21c due to the limited support period. Not unless you are prepared to upgrade the database soon again – when support runs out. Oracle Database 19c is the current Long Term Support release. I recommend that for production databases.

Different release types for Oracle Database - innovation vs long term support

To learn more about innovation release and our release model, have a look at our slide deck. We discuss it in the first chapter.

New Features

I want to mention a few new features. They haven’t attracted as much attention as the marque features, but they are still cool.

Expression based init.ora parameters make it possible to base database parameters (init.ora) on calculations made on the system’s configuration. For example, setting the database parameter CPU_COUNT to half the number of CPUs (Windows):

alter system set cpu_count='$NUMBER_OF_PROCESSORS/2';

For more details, check out my video on YouTube.

Placeholders in SQL DDL Statements can improve application security because sensitive information, like passwords, doesn’t need to be hardcoded in SQL DDL. Example: You can make this statement:

CREATE USER :!username IDENTIFIED BY :!password ...

And Oracle Call Interface programs can substitute the placeholders into:

CREATE USER "DANIEL" IDENTIFIED BY "MyS3cr3tP!d" ...

This is similar to data binding but occurs in Oracle Client.

Conclusion

The complete 21c documentation is online, so I suggest that you head on over there and have a look. In the upgrade guide, you can find the list of behavior changes and also deprecated and desupported functionality. And finally, but most interesting perhaps, is Learning Database New Features.

Try it out in Always Free ADB or explore the Oracle LiveLabs.

Zero Downtime Migration – Logical Migration and Statistics

If you decided to do a logical migration of your Oracle Database with Zero Downtime Migration (ZDM), here is something important about optimizer statistics. You must manually take care of the optimizer statistics on the target database after the Data Pump import. Either by recreating the statistics or transporting the statistics from the source database.

Background

Whenever I talk about migration of Oracle Database with Data Pump, I always mention that it is best practice to exclude optimizer statistics from the Data Pump export. Here is how you do it:

$ expdp ... exclude=statistics

Why is that recommended? Data Pump is not very good at extracting the optimizer statistics. There is nothing wrong with the statistics when they are imported. But it can take a very long time to do the export of statistics.

ZDM and Data Pump

The development team behind ZDM wanted the tool to be easy to use. Also, they wanted ZDM to use all the best practices that come with the various other tools that ZDM uses. When they talked to us about Data Pump, we told them to exclude statistics.

BUT – this also leaves you in a situation where you have a database completely without optimizer statistics. It goes without saying that it is a disaster waiting to happen. You must ensure that optimizer statistics are present on the target database before allowing the users to connect to it.

Regather

One option is to regather optimizer statistics on the target database after the Data Pump import. When the Data Pump import completes, and before you proceed with the switchover, it is time to regather the statistics. Typically, you would start ZDM something like this:

$ zdmcli migrate database .... -pauseafter ZDM_MONITOR_GG_LAG

It will start by performing the initial load of the database with Data Pump. Then it will configure GoldenGate before it pauses – waiting for your signal to complete the migration. At this time, use DBMS_STATS to gather statistics:

SQL> exec dbms_stats.gather_database_stats;

This has some drawbacks:

  • It requires time and resources – which might not be the biggest problem. The source database is still open for business. We haven’t performed the switchover yet.
  • Column usage information (table COL_USAGE$) is not populated, so in some cases, no histograms will be created. This will happen if the database is supposed to automatically determine whether histograms are needed (method_opt includes size auto). In that case, you can merge the column usage information from another database via a database link, which can be a good idea if your application is depending on histograms.
  • The table, schema, or database statistics preferences are not present. It could be degree, method_opt, stale_pct or any other preferences that you can set with DBMS_STATS.SET_TABLE_PREFS (or schema or database-wide preferences). These preferences can be transferred to the new system, which is what I will talk about next.

Transferring Statistics

Another option is to transfer the statistics using DBMS_STATS. We have covered this in detail in a webinar, so I suggest you watch Performance Stability, Tips and Tricks and Underscores for all the details.

In short,

  1. The optimizer statistics in the source database are extracted from the data dictionary and stored in a transportable format in a regular heap table (referred to as a staging table).
  2. Using Data Pump, you move that table to the target database.
  3. Then you put the statistics into the data dictionary of the target database so that optimizer can use them.

Pro tip: You should perform step #1 before you start ZDM and store the staging table in one of the schemas that you are migrating with ZDM. That way, you don’t have to move the table manually. It is moved by ZDM together with the real data.

One thing to be aware of is that the table, schema or database statistics preferences are not transferred when you use e.g. DBMS_STATS.EXPORT_TABLE_STATS. There are dedicated procedures for transferring the statistics preferences:

Conclusion

You must figure out how to move the optimizer statistics into your target database when you use ZDM to perform logical migrations. If not, your target database will be without optimizer statistics which is a disaster waiting to happen.

Appendix

You might now ask. If Data Pump is bad at exporting statistics, but there are already better ways available in the database, why don’t we change the Data Pump code? And you are right – but so far, other things have been prioritized. I would love to see this one day fully embedded in Data Pump.

Other Blog Posts in This Series

Zero Downtime Migration – Logical Online Migration and Testing

How can you test your OCI database before going live? With Logical Online migration it is possible using Flashback Database, restore or cloning. Let’s explore the options.

Flashback Database

Using Flashback Database is the easiest option and it is supported on all target platforms except Autonomous Database (shared and dedicated). In addition, your target database must be Enterprise Edition.

Does Oracle GoldenGate support Flashback Database? You can find the answer in the MOS note Does Goldengate Support Oracle RDBMS Flashback Features? (Doc ID 966212.1):

In a situation where there are only Replicats on a system, then FLASHBACK DATABASE… is fully supported if the Replicats are all using a checkpoint table and the trail files are available that go as far back as the flashback.

When you do Logical Online migrations you only have replicat process in your target database. In addition, checkpoint tables are enabled by default. All good!

Flashback Database – How To

  1. Stop replicat process by logging on to the GoldenGate hub and navigate to the Target Administration Server: How to stop replicat process in Oracle GoldenGate Microservices Architecture Hub
  2. Set a guaranteed restore point in the target PDB (named tgtpdb):
alter session set container=tgtpdb;
create restore point grp4test guarantee flashback database;
  1. Do your tests.
  2. Revert the changes by issuing a FLASHBACK PLUGGABLE DATABASE command:
alter session set container=cdb$root;
alter pluggable database tgtpdb close immediate;
flashback pluggable database tgtpdb to restore point grp4test;
alter pluggable database tgtpdb open resetlogs;
  1. Restart replicat process: How to start replicat process in Oracle GoldenGate Microservices Architecture Hub

The above procedure uses flashback of the pluggable database. This feature was introduced in Oracle Database 12.2. If your target database is 12.1 or older, you have to flashback the entire CDB. If your target database is a non-CDB database, you have to flashback back the entire database.

Restore

Backup/restore is also an option. In OCI it is easy to backup and restore, however, it does take longer than using Flashback Database. But the good thing is that you get to test your OCI backup and recovery strategy.

For Autonomous Database you can use the automatic backups which are enabled by default. In the other Database Cloud Offerings, you must enable automatic backup yourself.

Restore – How To

  1. Stop replicat process (see above)
  2. Create backup (or rely on automatic backup)
  3. Do your tests
  4. Restore backup
  5. Restart replicat process (see above)

Clone

Cloning the database or the entire DB System is also an option. A benefit is that the GoldenGate replication can continue while you are doing the tests. When you use Flashback Database and restore the replication must be stopped. Trail files will accumulate on disk and at one point the target database will be very busy catching up with the lag. For very huge and active systems it might be desirable to work on a clone. However, cloning to a new system mean that you are no longer testing in that specific database that will be your future production database. Also, cloning involves creating new DB Systems which has a cost.

Clone – How To

  1. Clone database or DB System
  2. Do your tests
  3. Discard database or DB System

Conclusion

Before going live in your new OCI database, you should test it. With Logical Online method it is easy, and you can use well-known techniques. If you combine it with the recommendations from our webinar Performance Stability, Tips and Tricks and Underscores, you are well underway towards a successful migration.

Other Blog Posts in This Series

Zero Downtime Migration – Physical Online Migration of Very Large Databases

Following the blog post on migrating Very Large Databases (VLDBs) using Logical Online method, let’s touch upon the Physical Online method as well.

Existing Data Guard

VLDBs are very often protected by Data Guard with one or more standby databases. When you start a migration with Zero Downtime Migration (ZDM) you don’t want to promise your existing Data Guard setup. If something happens during the preparation of the migration to OCI, you still want to be able to switch over to an on-prem standby database. Something like this:

Setup with on-prem Oracle Database Data Guard and standby database in OCI

When ZDM configure the OCI standby database, it will be added as a manually managed database, i.e. it does not use Data Guard broker. It does not interfere with your Data Guard broker setup and the setup remains valid. A few things to observe:

  • When ZDM is working, no switch-overs are allowed. This will cause the process to error out.
  • By working I mean – from the second you start the ZDM migration and until it is paused at ZDM_CONFIGURE_DG_SRC.
  • When ZDM is paused, you can do as many switch-overs as you like. Just ensure that the original source database become the primary database again as soon as possible.
  • When you need to complete the migration, the source database must be the primary database and no switch-overs are allowed. Which does make sense because in this last phase, ZDM is switching over to the OCI target database.
  • What about fail-overs. Fail-overs means loss of data and to accept that you need to open the database with RESETLOGS. This causes all sort of havoc in your Data Guard setup. You are back to start.

At which phases can you switch over to your on-prem standby database without jeopardizing the ZDM migration

Important

But you must remove your on-prem Data Guard setup, before you complete the migration with ZDM, i.e. you resume the paused job. ZDM will not be able to finish properly if there is a conflicting Data Guard configuration. To remove your existing Data Guard setup:

  1. ZDM migration is currently paused at ZDM_CONFIGURE_DG_SRC.
  2. Connect using Data Guard CLI (dgmgrl) to source on-prem database (primary). Remove configuration:
remove configuration
  1. Connect using SQL*Plus (sqlplus) to source on-prem database (primary). Remove Data Guard broker configuration:
alter system set dg_broker_start=FALSE scope=memory;
alter system reset dg_broker_start;
alter system reset dg_broker_config_file1;
alter system reset dg_broker_config_file2;
  1. Check log_archive_config. It must contain DB_UNIQUE_NAME of the source on-prem database (primary) and the OCI target database – nothing else. Using the above example, it should be:
alter system set log_archive_config='dg_config=(SALES_1,SALES_oci)' scope=both;
  1. Check log_archive_dest_n parameters. Ensure that Data Guard broker removed the correct ones. There should only be one remote redo log destination – and that is the OCI target database – all others should be removed. If you need to remove one, use this command (remember adjusting the suffix):
alter system set log_archive_dest_2='' scope=memory;
alter system reset log_archive_dest_2;
  1. Ensure that log_archive_config is set correctly (like #4) in the OCI target database:
alter system set log_archive_config='dg_config=(SALES_1,SALES_oci)' scope=both;
  1. Finally, complete migration:
$ZDM_HOME/bin/zdmcli resume job -jobid <id>

The Backup

ZDM needs a full backup that can be restored on your target.

  • DBCS: If your target database is one of the OCI Cloud Services (Virtual Machine, Bare Metal or Exadata DB System), ZDM will need to take a new full backup. Existing backups can’t be used.
  • ExaCC or Exadata on-prem: You can either take a new full backup or use an existing backup that is made available on disk. In addition, if you are so fortunate to have a Zero Data Loss Recovery Appliance (ZDLRA), you don’t need to take a backup. ZDM can just restore directly from ZDLRA.

If you are targeting a DBCS your DATA_TRANSFER_MEDIUM is set to OSS (Object Storage Service). The backup is stored in Object Storage using Oracle Database Cloud Backup Module for OCI. The backup in the source database and the restore in the target database will happen via a special sbt channel which streams the backup directly to and from Object Storage. This means:

  • The backup never hits the disk, so you don’t need additional disk space to hold the backup.
  • The duration of the backup is depending on your network speed to OCI. Since the backup is streamed directly to OCI, the network can become a bottleneck. If you have a slow connection to OCI, the backup will run equally slow. The same applies about the restore, however, the target database is already in OCI and does have a good connection to Object Storage.

ZDM will by default use 10 RMAN channels for the restore and the backup. With your knowledge of the source database, you might know better. You can tweak the number of channels in the response file. Look for the parameters SRC_RMAN_CHANNELS and TGT_RMAN_CHANNELS.

Based on your knowledge or testing you can determine which RMAN Compression algorithm that gives the best benefit on your database. You can adjust the compression algorithm in the response file using the parameter ZDM_RMAN_COMPRESSION_ALGORITHM. The default is MEDIUM which is normally gives the best balance between compression ratio and CPU time. And remember, RMAN Compression normally require a license for Advanced Compression Option but when you migrate with ZDM, you can use it for free.

While ZDM is taking a backup of the source database, no other backups should be running. Be sure to put your regular backups, including archive backups, on hold.

Redo Apply

In the source database, you should keep archive logs on disk until the target database has been restored, Data Guard has been configured, and the target database has caught up with redo apply. If you have a slow network connection and a huge database, it can take days until the backup has completed, restored has completed and redo apply has caught up.

  • Imagine you start the backup at sequence 100.
  • The restore of the target database finishes two days later. The source database is now at sequence 200.
  • ZDM configure Data Guard and starts redo transfer and redo apply. The source database is now at sequence 220.
  • Sequences 100-220 must be available on disk on the source database host, so the source (primary) database can transfer them to the target (standby) database.

It is not uncommon for VLDBs to generate redo on a daily basis that are double-digit TB. Just the other day I talked to a customer whose database generated 15 TB of archive logs a day.

First, you must be able to transfer the redo from the source database (primary) to the target database (standby). This is simple math: If you have 15 TB redo a day, you should be able to transfer that using a 1,5 Gbps connection (amount of redo / 24 / 60 / 60 * 8). If transferring redo becomes a problem, you can look into using redo transport compression. This can reduce the amount of data that must be transferred at the cost of CPU cycles. You can read more about it in the MOS note Redo Transport Compression in a Data Guard Environment (Doc ID 729551.1). I learned from colleagues in the Maximum Availability Architecture (MAA) team that TDE Tablespace Encryption and redo transport compression doesn’t play very well together. If your source database is encrypted, you should not expect that much benefit from redo transport compression.

Next, redo must be applied on the target database. Is the target database capable of applying redo so fast? On Exadata the answer is most likely: YES – but as always in IT, it depends. Redo Apply benchmark of Oracle Database Data Guard The numbers of the above graph comes from Redo Apply Best Practices – Oracle Data Guard and Active Data Guard. Based on your database release and the type of workload you have in the database; you can see the amount of redo that can be applied daily (in TB). The last two columns are using Multi-Instance Redo Apply (MIRA) with either two or four active RAC nodes. The numbers were generated on an Exadata.

Backup of Target Database

How do you backup your target database in OCI? You want to have a valid backup from the very second that you switch over to the target database.

The target placeholder database that you originally created will be overwritten by ZDM. This means that you can’t configure and enable automatic backup in OCI in advance. You must wait until the migration has completed until you enable automatic backup.

You could:

  • Extend the downtime window to allow automatic backup to be configured after the migration. Also, allow enough time for the first backup to complete.
  • Or, do your own backup in OCI. This is more cumbersome but will allow you to open the database for business immediately after the switchover. But you are in charge of the backup now. All the various bits and pieces are available:
    • Original backup is still in object storage.
    • Archive logs are on disk – you can back them up manually.
    • Perform incrementals if needed – put them somewhere safe.
    • In case of emergency – glue it all together

Data Guard on Target Database

Similar to automatic backup, you can’t create a Data Guard Association until ZDM has completed the migration. The cloud tooling does not support creating the standby database through a cascading standby. This means that you can’t build your OCI standby database until after ZDM has completed the migration – and the OCI database is the primary database. You can start to create the OCI Data Guard as soon as ZDM is done, but

  • You must tolerate that the OCI Data Guard is missing
  • Or, take downtime

Conclusion

Even huge Oracle Databases can be migrated to OCI using Zero Downtime Migration. You might need to make a few adjustments from the standard flow, but it is absolutely doable. Automatic backup and data guard can’t be created in OCI until after the migration. This might force you to take downtime. Besides the actual migration, you should also do your best to ensure performance stability once the database is open for business. For that purpose, you should have a look at our webinar Performance Stability, Tips and Tricks and Underscores.

Other Blog Posts in This Series

Zero Downtime Migration – Physical Online Migration to ExaCS

This will be an easy blog post. To migrate your Oracle Database to Exadata DB System (ExaCS), just follow this procedure from the DBCS blog post. Plus, execute these two commands on the target after the migration:

[root@tgthost]$ dbaascli registerdb prereqs --dbname [db_name] --db_unique_name [db_unique_name]
[root@tgthost]$ dbaascli registerdb begin --dbname [db_name] --db_unique_name [db_unique_name]

More Details, Please

Granted – the above statement is bold and it is almost true. There are a few important details to share. First, have a look at Additional Information for Migrating to Exadata Cloud Service which you find the Release Notes

Target Environment

To get the full benefits of Exadata you should be running RAC databases. Exadata and RAC is a perfect match but it is up to you to decide. If your source database is already a RAC database (or RAC One Node) you must migrate to a RAC database. However, if your source database is a single instance you have to option to either stay single instance or go RAC. If you go RAC, just create the target placeholder database as a RAC database, and everything else will happen automatically.

You must create a placeholder database on the target system. The placeholder database gets overwritten ZDM during the migration but it is initially used by ZDM to get information on how you want to configure your target database in OCI. For example, the migrated database will be placed in the same Oracle Home as the target placeholder database. Also, the architecture is determined this way. In other words, if you create the target placeholder database as a RAC database; then your source database is automatically converted to a RAC database during migration. If you create a single instance placeholder database; you get a single instance database.

Just like any other migration, when creating the placeholder database there are some things you should be aware of. On the OCI webpage you have to:

  • Set Database name to the DB_NAME of the source database.
  • Set Database version to the same as the source database.
  • Ensure the patch level of the Oracle Home match that of the source system – or be higher.
  • Ensure that the Password matches the SYS password of the source database.

When using Zero Downtime Migration (ZDM) to migrate to Exadata DB System (ExaCS) be sure to create the target placeholder database in the correct manner.

You can choose your own DB_UNIQUE_NAME – it should differ from the source database. Select an Oracle Home that has the same or higher patch level than your source database. I recommend to always migrate to the latest Release Update. If necessary, ZDM will automatically invoke datapatch after the switchover. The other parameters don’t matter – the database gets overwritten anyway by ZDM. Also, be aware when using the OCI webpage you get a RAC database. There is no option to change it. But it is after all the perfect match for Exadata anyway.

Now, if you want more advanced options – like creating a single instance database, you can’t use the OCI webpage. You will have to use either dbaaspi or dbaascli. That gives you full control over the options – but they are not as easy to use as the webpage.

It’s A Wrap

I have created a video on YouTube that demos a migration to Exadata DB System.

Speaking of YouTube, I suggest that you subscribe to the Oracle Database Upgrades and Migrations YouTube channel so you never miss anything.

The Exadata Cloud Service is an awesome platform and it is really easy to migrate to it using Zero Downtime Migration. And converting to RAC is even easier.

Other Blog Posts in This Series
