Grid Infrastructure 19c Out-Of-Place Patching Fails on AIX

I’m a strong advocate for out-of-place patching, and I can see that many of my blog readers are interested in that topic as well. Thank you for that!

But a reader notified me about a specific issue that occurs during out-of-place patching of Oracle Grid Infrastructure 19c. The issue occurs when using OPatchAuto as well as SwitchGridHome.

Normally, I recommend creating a new Oracle home using the base release (so 19.3.0) and then applying the latest Release Update on top:

# Unzipping base release, 19.3.0
unzip -oq /u01/software/LINUX.X64_193000_grid_home.zip
# Install and patch Oracle home
./gridSetup.sh -ignorePrereq -waitforcompletion -silent \
   -applyRU ...

However, that fails on AIX:

Preparing the home to patch...
Applying the patch /u01/software/36916690/36916690/36917416...
OPatch command failed while applying the patch. For details look at the logs
from /u01/app/19.25.0/grid/cfgtoollogs/opatchauto/.

The log file has a little more detail:

DeleteAction : Destination File ''/u01/app/19.25.0/grid/perl/bin/perl'' is not writeable.
Copy Action: Destination File ''/u01/app/19.25.0/grid/perl/bin/perl'' is not writeable.

The Solution

There is already a MOS note that describes a potential workaround:

Out of place (OOP) patching of 19c Release Update (RU) fails on AIX (Doc ID 2948468.1)

But the reader leaving the comment asked for a few more words.

My Words

First, you should continue to use out-of-place patching despite the above issue.

Second, instead of using the base release (19.3.0) as the basis for any new Oracle home, you must create a new base release. One that doesn’t contain the error that leads to the above issue.

  1. On a non-prod system, create a brand-new Grid Infrastructure installation using the base release (19.3.0).
  2. Use in-place patching to patch it to the latest Release Update (currently 19.25.0). You need to add a few parameters to the opatchauto command:
    <path_to_temp_home>/OPatch/opatchauto \
   apply <path-to-patch> \
   -binary \
   -oh <path_to_temp_home> \
   -target_type cluster
  3. Create a gold image of this 19.25.0 Oracle home.
    export NEW_GRID_HOME=/u01/app/19.25.0/grid
$NEW_GRID_HOME/gridSetup.sh -createGoldImage \
   -destinationLocation $GOLDIMAGEDIR \
   -name gi_gold_image.zip \
   -silent
  4. You now have a new base release. It is almost as pristine as the 19.3.0 base release. It just contains the additional Release Update (19.3.0 + 19.25.0).
  5. When you need to patch another system, use out-of-place patching using SwitchGridHome. But instead of using the base release 19.3.0, you use your new gold image that is already patched to 19.25.0.
    #Don't do this
#unzip -oq /u01/software/LINUX.X64_193000_grid_home.zip
#Do this
unzip -oq /u01/software/gi_gold_image.zip
  6. When you install the using gridSetup.sh you don’t have to apply the Release Update because the gold image contains it already. You can still apply any one-offs you need.
    ./gridSetup.sh -ignorePrereq -waitforcompletion -silent \
   -applyOneOffs <path_to_one_offs> \
   ...
  • There are no other changes to the procedure.

The issue is fixed in bug 34962446. However, I doesn’t seem to be available in 19c, so you have to repeat the above process for every Release Update.

If you still run into patching the Perl component, take a look at this MOS note:

Final Words

  • Is it a viable workaround? Yes, I believe so. There’s a little more work to, on the other hard, you’ve now started to use gold images, which is a huge advantage.

  • If you continue patching in-place or out-of-place using OPatchAuto, be sure to clean up the Oracle home from time to time.

  • The issue occurs starting with Release Update 19.18 because that’s where Oracle started to add patches to Perl in the Oracle home.

  • Thanks to Axel Dellin for helping me with some details.

You should not let this little bump on the road prevent you from using out-of-place patching.

Happy Patching

How to Patch Oracle Restart 19c and Oracle Database Using Out-Of-Place Switch Home

Let me show you how I patch Oracle Restart and Oracle Database 19c using the out-of-place method by switching to the new Oracle homes.

The advantages of this solution:

  • I get more control over the process
  • I can perform the entire operation with just one database restart
  • I can create my Oracle homes using gold images
  • I can prepare the new Oracle homes in advance
  • Overall, I find this method less riskier

My demo system

  • Single instance database in Oracle Restart configuration
  • Runs Oracle Linux
  • GI and database home are currently on 19.24

I want to:

  • patch to 19.25
  • patch both the GI and database home in one operation

Preparation

I need to download:

  1. The base releases of:
    • Oracle Grid Infrastructure (LINUX.X64_193000_grid_home.zip)
    • Oracle Database (LINUX.X64_193000_db_home.zip)
  2. Latest OPatch from My Oracle Support (6880880).
  3. Patches from My Oracle Support:
    • 19.25 Release Update for Grid Infrastructure (36916690)
    • Matching OJVM bundle patch (36878697)
    • Matching Data Pump bundle patch (36682332)

You can use AutoUpgrade to easily download GI patches.

I place the software in /u01/software.

How to Patch Oracle Restart 19c and Oracle Database

1. Prepare a New GI Home

I can do this in advance. It doesn’t affect my current environment and doesn’t cause any downtime.

  1. I need to create a folder for the new GI home. I must do this as root:

    [root@node1]$ mkdir -p /u01/app/19.25.0/grid
[root@node1]$ chown -R grid:oinstall /u01/app/19.25.0
[root@node1]$ chmod -R 775 /u01/app/19.25.0

  2. I switch to the GI home owner, grid.

  3. I extract the base release of Oracle Grid Infrastructure into the new GI home:

    [grid@node1]$ export OLDGRIDHOME=$ORACLE_HOME
[grid@node1]$ export NEWGRIDHOME=/u01/app/19.25.0/grid
[grid@node1]$ cd $NEWGRIDHOME
[grid@node1]$ unzip -oq /u01/software/LINUX.X64_193000_grid_home.zip

    Optionally, I can use a golden image.

  4. I update OPatch to the latest version:

    [grid@node1]$ cd $NEWGRIDHOME
[grid@node1]$ rm -rf OPatch
[grid@node1]$ unzip -oq /u01/software/p6880880_190000_Linux-x86-64.zip

  5. Then, I check the Oracle Grid Infrastructure prerequisites. I am good to go if the check doesn’t write any error messages to the console:

    [grid@node1]$ export ORACLE_HOME=$NEWGRIDHOME
[grid@node1]$ $ORACLE_HOME/gridSetup.sh -executePrereqs -silent

  6. I want to apply the 19.25 Release Update while I install the GI home. To do that, I must extract the patch file:

     [grid@node1]$ cd /u01/software
 [grid@node1]$ unzip -oq p36916690_190000_Linux-x86-64.zip -d 36916690
    • The GI Release Update is a bundle patch consisting of:
      • OCW Release Update (patch 36917416)
      • Database Release Update (36912597)
      • ACFS Release Update (36917397)
      • Tomcat Release Update (36940756)
      • DBWLM Release Update (36758186)
    • I will apply all of them.

  7. Finally, I can install the new GI home:

    • The parameter -applyRU is the path to the OCW Release Update.
    • The parameter -applyOneOffs is a comma-separated list of the paths to each of the other Release Updates in the GI bundle patch.
    • The environment variable CLUSTER_NAME is the name of my Oracle Restart stack.
    [grid@node1]$ export ORACLE_BASE=/u01/app/grid
[grid@node1]$ export ORA_INVENTORY=/u01/app/oraInventory
[grid@node1]$ export ORACLE_HOME=$NEWGRIDHOME
[grid@node1]$ cd $ORACLE_HOME
[grid@node1]$ ./gridSetup.sh -ignorePrereq -waitforcompletion -silent \
   -applyRU /u01/software/36916690/36916690/36917416 \
   -applyOneOffs /u01/software/36916690/36916690/36912597,/u01/software/36916690/36916690/36917397,/u01/software/36916690/36916690/36940756,/u01/software/36916690/36916690/36758186 \ \
   -responseFile $ORACLE_HOME/install/response/gridsetup.rsp \
   INVENTORY_LOCATION=$ORA_INVENTORY \
   ORACLE_BASE=$ORACLE_BASE \
   SELECTED_LANGUAGES=en \
   oracle.install.option=CRS_SWONLY \
   oracle.install.asm.OSDBA=asmdba \
   oracle.install.asm.OSOPER=asmoper \
   oracle.install.asm.OSASM=asmadmin \
   oracle.install.crs.config.ClusterConfiguration=STANDALONE \
   oracle.install.crs.config.configureAsExtendedCluster=false \oracle.install.crs.config.gpnp.configureGNS=false \
   oracle.install.crs.config.autoConfigureClusterNodeVIP=false
    • Although the script says so, I don’t run root.sh.
    • I install it in silent mode, but I could use the wizard instead.
    • You need to install the new GI home in a way that matches your environment.
    • For inspiration, you can check the response file used in the previous GI home on setting the various parameters.
    • If I have additional one-off patches to install, I add them to the comma-separated list.

2. Prepare a New Database Home

I can do this in advance. It doesn’t affect my current environment and doesn’t cause any downtime.

  1. I need to create a folder for the new database home. I must do this as oracle:

    [oracle@node1]$ export NEW_ORACLE_HOME=/u01/app/oracle/product/dbhome_1925
[oracle@node1]$ mkdir -p $NEW_ORACLE_HOME

  2. I extract the base release of Oracle Database into the new database home:

    [oracle@node1]$ cd $NEW_ORACLE_HOME
[oracle@node1]$ unzip -oq /u01/software/LINUX.X64_193000_db_home.zip

    Optionally, I can use a golden image.

  3. I update OPatch to the latest version:

    [oracle@node1]$ rm -rf OPatch
[oracle@node1]$ unzip -oq /u01/software/p6880880_190000_Linux-x86-64.zip

  4. I want to apply the 19.25 Database Release Update. In addition, I must also apply the OCW Release Update to the database home. I take those from the GI Release Update that I used earlier. In addition, I want to apply the OJVM and Data Pump bundle patches. Those I must extract.

    [oracle@node1]$ cd /u01/software
[oracle@node1]$ unzip -oq p36878697_190000_Linux-x86-64.zip -d 36878697
[oracle@node1]$ unzip -oq p37056207_1925000DBRU_Generic_1925.zip -d 37056207

  5. Then, I can install the new database home and apply the patches at the same time:

    • The parameter -applyRU is the path to the Database Release Update.
    • The parameter -applyOneOffs is a comma-separated list of the paths to the OCW Release Update plus OJVM and Data Pump bundle patches.
    [oracle@node1]$ export ORACLE_BASE=/u01/app/grid
[oracle@node1]$ export ORA_INVENTORY=/u01/app/oraInventory
[oracle@node1]$ export OLD_ORACLE_HOME=$ORACLE_HOME
[oracle@node1]$ export ORACLE_HOME=$NEW_ORACLE_HOME
[oracle@node1]$ cd $ORACLE_HOME
[oracle@node1]$ ./runInstaller -ignorePrereqFailure -waitforcompletion -silent \
     -responseFile $ORACLE_HOME/install/response/db_install.rsp \
     -applyRU /u01/software/36916690/36916690/36912597 \
     -applyOneOffs /u01/software/36916690/36916690/36917416,/u01/software/36878697/36878697,/u01/software/37056207/37056207 \
     oracle.install.option=INSTALL_DB_SWONLY \
     UNIX_GROUP_NAME=oinstall \
     INVENTORY_LOCATION=$ORA_INVENTORY \
     SELECTED_LANGUAGES=en \
     ORACLE_HOME=$ORACLE_HOME \
     ORACLE_BASE=$ORACLE_BASE \
     oracle.install.db.InstallEdition=EE \
     oracle.install.db.OSDBA_GROUP=dba \
     oracle.install.db.OSBACKUPDBA_GROUP=dba \
     oracle.install.db.OSDGDBA_GROUP=dba \
     oracle.install.db.OSKMDBA_GROUP=dba \
     oracle.install.db.OSRACDBA_GROUP=dba \
     oracle.install.db.isRACOneInstall=false \
     oracle.install.db.rac.serverpoolCardinality=0 \
     SECURITY_UPDATES_VIA_MYORACLESUPPORT=false \
     DECLINE_SECURITY_UPDATES=true
    • I install it in silent mode, but I could use the wizard instead.
    • You need to install the new database home in a way that matches your environment.
    • For inspiration, you can check the response file used in the previous database home on setting the various parameters.
    • If I have additional one-off patches to install, I add them to the comma-separated list.

  6. I run the database root script:

    [root@node1]$ $NEW_ORACLE_HOME/root.sh
    • I run just the database root script. Not the GI root script.

3. Prepare Database

I can do this in advance. It doesn’t affect my current environment and doesn’t cause any downtime.

I will move the database into a new Oracle home, so I need to ensure the database configuration files are either outside the Oracle home or move them to the new Oracle home.

  1. I verify that my SP file and password file are stored in ASM – or at least outside the Oracle home:
    [oracle@node1]$ export ORACLE_HOME=$OLD_ORACLE_HOME
[oracle@node1]$ srvctl config database -db $ORACLE_UNQNAME | grep file
    • If the files are stored in the dbs folder, I copy them to new Oracle home.
  2. I copy tnsnames.ora and sqlnet.ora to the new Oracle home:
    [oracle@node1]$ cp $OLD_ORACLE_HOME/network/admin/sqlnet.ora $NEW_ORACLE_HOME/network/admin
[oracle@node1]$ cp $OLD_ORACLE_HOME/network/admin/tnsnames.ora $NEW_ORACLE_HOME/network/admin
  3. I take care of any other configuration files in the Oracle home.
  4. I modify the database so it starts in the new Oracle home on the next restart.
    [oracle@node1]$ srvctl modify database -d $ORACLE_UNQNAME -o $NEW_ORACLE_HOME

4. Switch to the New GI and Database Homes

Now, I can complete the patching process by switching to the new Oracle homes.

  1. I connect as root and start the switch:

    [root@node1]$ export ORACLE_HOME=/u01/app/19.25.0/grid
[root@node1]$ $ORACLE_HOME/rdbms/install/rootadd_rdbms.sh
[root@node1]$ $ORACLE_HOME/crs/install/roothas.sh -prepatch -dstcrshome $ORACLE_HOME

  2. Downtime starts now!

  3. Then, I complete the switch.

    • This step stops the entire GI stack, including resources it manages (databases, listener, etc.).
    • Everything is restarted in the new Oracle homes.
    [root@node1]$ $ORACLE_HOME/crs/install/roothas.sh -postpatch -dstcrshome $ORACLE_HOME

  4. Downtime ends now. Users may connect to the database.

  5. As grid, I update the inventory, so the new GI home is registered as the active one:

    [grid@node1]$ export OLD_ORACLE_HOME=/u01/app/19.24.0/grid
[grid@node1]$ export NEW_ORACLE_HOME=/u01/app/19.25.0/grid
[grid@node1]$ $NEW_ORACLE_HOME/oui/bin/runInstaller -updateNodeList ORACLE_HOME=$NEW_ORACLE_HOME CRS=TRUE
[grid@node1]$ $OLD_ORACLE_HOME/oui/bin/runInstaller -updateNodeList ORACLE_HOME=$OLD_ORACLE_HOME CRS=FALSE

  6. I update any profiles (e.g., .bash_profile) and other scripts referring to the GI home.

  7. As oracle, I update any profiles (e.g., .bash_profile) and other scripts referring to the database home.

5. Complete Patching

  1. I complete patching of the database by running Datapatch (ensure the environment is set correctly):
    [oracle@node1]$ env | grep ORA
[oracle@node1]$ $ORACLE_HOME/OPatch/datapatch

Most likely, there are other changes that you need to make in your own environment:

  • Update Enterprise Manager registration
  • Upgrade RMAN catalog
  • Update other scripts
  • Update /etc/oratab

That’s it! I have now patched my Oracle Restart deployment.

Happy Patching!

Appendix

Deinstall

In the future, I should remove the old Oracle homes. I use the deinstall tool in the respective Oracle homes.

I would recommend waiting a week or two until I’m confident the new Release Updates are fine.

CRS-0245: User doesn’t have enough privilege to perform the operation

  • If you get the following error:
    [oracle@node1]$ srvctl modify database -d $ORACLE_UNQNAME -o $NEW_ORACLE_HOME
PRCD-1163 : Failed to modify database DB19
PRCR-1071 : Failed to register or update resource ora.db19.db
CRS-0245:  User doesn't have enough privilege to perform the operation
  • Be sure to include patch 29326865 in GI and database home.
  • Run the srvctl modify database command as grid instead.
  • Be sure that the Oracle user is still set to oracle after running the command as grid:
    [oracle@node1]$ srvctl config database -db $ORACLE_UNQNAME | grep user

Rollback

If you need to roll back, you more or less reverse the process. The switch home method works to a newer and lower patch level.

OCW Release Update

Thanks to Jan for commenting on the blog post. The initial version didn’t include the OCW Release Update into the database home, which is needed when the database is managed by Grid Infrastructure in any way.

Incorrect Information in ocr.loc

In the ocr.loc file for Oracle Restart, only the local_only property is used. All other properties can be ignored (like ocrconfig_loc).

In Oracle Database 23ai, the file will be cleaner in Oracle Restart. But for Oracle Database 19c there will be these superfluous properties.

Further Reading

Other Blog Posts in This Series

How to Roll Back Oracle Grid Infrastructure 19c Using SwitchGridHome

Let me show you how I roll back a patch from Oracle Grid Infrastructure 19c (GI) using the out-of-place method and the -switchGridHome parameter.

My demo system:

  • Is a 2-node RAC (nodes copenhagen1 and copenhagen2).
  • Runs Oracle Linux.
  • Was patched from 19.17.0 to 19.19.0. I patched both GI and database. Now I want GI back on 19.17.0.

I only roll back the GI home. See the appendix for a few thoughts on rolling back the database as well.

This method works if you applied the patch out-of-place – regardless of whether you used the OPatchAuto or SwitchGridHome method.

Preparation

  • I use the term old Oracle Home for the original, lower patch level Oracle Home.

    • It is my 19.17.0 Oracle Home
    • It is stored in /u01/app/19.0.0.0/grid
    • I refer to this home using the environment variable OLD_ORACLE_HOME
    • This is the Oracle Home that I want to roll back to

  • I use the term new Oracle Home for the higher patch level Oracle Home.

    • It is my 19.19.0 Oracle Home
    • It is stored in /u01/app/19.19.0/grid
    • I refer to this home using the environment variable NEW_ORACLE_HOME
    • This is the Oracle Home that I want to roll back from

Both GI homes are present in the system already.

How to Roll Back Oracle Grid Infrastructure 19c

1. Sanity Checks

I execute the following checks on both nodes, copenhagen1 and copenhagen2. I show the commands for one node only.

  • I verify that the active GI home is the new GI home:

    [grid@copenhagen1]$ export ORACLE_HOME=$NEW_GRID_HOME
[grid@copenhagen1]$ $ORACLE_HOME/srvm/admin/getcrshome

  • I verify that the cluster upgrade state is NORMAL:

    [grid@copenhagen1]$ $ORACLE_HOME/bin/crsctl query crs activeversion -f

  • I verify all CRS services are online:

    [grid@copenhagen1]$ $ORACLE_HOME/bin/crsctl check cluster

  • I verify that the cluster patch level is 19.19.0 – the new patch level:

    [grid@copenhagen1]$ $ORACLE_HOME/bin/crsctl query crs releasepatch

2. Cluster Verification Utility

  • I use Cluster Verification Utility (CVU) to verify that my cluster meets all prerequisites for a patch/rollback. I do this on one node only:
    [grid@copenhagen1]$ $CVU_HOME/bin/cluvfy stage -pre patch
    • You can find CVU in the GI home, but I recommend always getting the latest version from My Oracle Support.

3. Roll Back Node 1

The GI stack (including database, listener, etc.) needs to restart on each instance. But I do the rollback in a rolling manner, so the database stays up all the time.

  • I drain connections from the first node, copenhagen1.

  • I unlock the old GI home, root:

    [root@copenhagen1]$ export OLD_GRID_HOME=/u01/app/19.0.0.0/grid
[root@copenhagen1]$ cd $OLD_GRID_HOME/crs/install
[root@copenhagen1]$ ./rootcrs.sh -unlock -crshome $OLD_GRID_HOME
    • This is required because the next step (gridSetup.sh) runs as grid and must have access to the GI home.
    • Later on, when I run root.sh, the script will lock the GI home.

  • I switch to old GI home as grid:

    [grid@copenhagen1]$ export OLD_GRID_HOME=/u01/app/19.0.0.0/grid
[grid@copenhagen1]$ export ORACLE_HOME=$OLD_GRID_HOME
[grid@copenhagen1]$ export CURRENT_NODE=$(hostname)
[grid@copenhagen1]$ $ORACLE_HOME/gridSetup.sh \
   -silent -switchGridHome \
   oracle.install.option=CRS_SWONLY \
   ORACLE_HOME=$ORACLE_HOME \
   oracle.install.crs.config.clusterNodes=$CURRENT_NODE \
   oracle.install.crs.rootconfig.executeRootScript=false

  • I complete the switch by running root.sh as root:

    [root@copenhagen1]$ export OLD_GRID_HOME=/u01/app/19.0.0.0/grid
[root@copenhagen1]$ $OLD_GRID_HOME/root.sh
    • This step restarts the entire GI stack, including resources it manages (databases, listener, etc.). This means downtime on this node only. The remaining nodes stay up.
    • In that period, GI marks the services as OFFLINE so users can connect to other nodes.
    • If my database listener runs out of the Grid Home, GI will move it to the new Grid Home, including copying listener.ora.
    • In the end, GI restarts the resources (databases and the like).

  • I update any profiles (e.g., .bashrc) and other scripts referring to the GI home.

  • I verify that the active GI home is the new GI home:

    [grid@copenhagen1]$ $OLD_ORACLE_HOME/srvm/admin/getcrshome

  • I verify that the cluster upgrade state is ROLLING PATCH:

    [grid@copenhagen1]$ $OLD_ORACLE_HOME/bin/crsctl query crs activeversion -f

  • I verify all CRS services are online:

    [grid@copenhagen1]$ $OLD_ORACLE_HOME/bin/crsctl check cluster

  • I verify all resources are online:

    [grid@copenhagen1]$ $OLD_ORACLE_HOME/bin/crsctl stat resource -t

  • I verify that the GI patch level is 19.17.0 – the old patch level:

    [grid@copenhagen1]$ $OLD_ORACLE_HOME/bin/crsctl query crs releasepatch

4. Roll Back Node 2

  • I roll back the second node, copenhagen2, using the same process as the first node, copenhagen1.
    • I double-check that the CURRENT_NODE environment variable gets updated to copenhagen2.
    • When I use crsctl query crs activeversion -f to check the cluster upgrade state, it will now be back in NORMAL mode, because copenhagen2 is the last node in the cluster.

5. Cluster Verification Utility

  • I use Cluster Verification Utility (CVU) again. Now I perform a post-rollback check. I do this on one node only:
    [grid@copenhagen1]$ $CVU_HOME/bin/cluvfy stage -post patch

That’s it!

My cluster is now operating at the previous patch level.

Appendix

SwitchGridHome Does Not Have Dedicated Rollback Functionality

OPatchAuto has dedicated rollback functionality that will revert the previous patch operation. Similar functionality does not exist when you use the SwitchGridHome method.

This is described in Steps for Minimal Downtime Grid Infrastructure Out of Place ( OOP ) Patching using gridSetup.sh (Doc ID 2662762.1). To rollback, simply switch back to the previous GI home using the same method as for the patch.

There is no real rollback option as this is a switch from OLD_HOME to NEW_HOME To return to the old version you need to recreate another new home and switch to that.

Should I Roll Back the Database as Well?

This post describes rolling back the GI home only. Usually, I recommend keeping the database and GI patch level in sync. If I roll back GI, should I also roll back the database?

The short answer is no!

Keeping the GI and database patch in sync is a good idea. But when you need to roll back, you are in a contingency. Only roll back the component that gives you problems. Then, you will be out of sync for a period of time until you can get a one-off patch or move to the next Release Update. Being in this state for a shorter period is perfectly fine – and supported.

Other Blog Posts in This Series
