Why Are You Not Using Bigfile Tablespaces?

Recently, I worked on two cases that could be solved using bigfile tablespaces.

Bigfile tablespaces have been around for ages but are typically not the default. If you use the CREATE TABLESPACE command and don’t specify a tablespace type, you will probably get a smallfile tablespace.

In a smallfile tablespace in an 8k block size database, each data file can only be 32 GB. For a huge tablespace – double-digit TB – you end up with many files. In a bigfile tablespace, there is only one data file, but it can grow up to 32 TB. Further, Oracle Autonomous Database comes with bigfile tablespaces.

Frustrated over the problems with smallfile tablespaces, I wanted to understand the reluctance to use bigfile tablespace.

I asked around: Why are you not using bigfile tablespaces?

The Answers

They Take a Long Time to Back Up

True, unless you use multisection backups. If so, multiple channels can work on the same data file and you should not see performance bottlenecks on bigfile tablespaces.

It’s very simple to perform multisection backups. Simply add the section size clause to the RMAN backup command.

RMAN> backup database ... section size 30G ...

Recovering a Bigfile Data File Is a Pain

If you accidentally delete a bigfile data file, it is very time-consuming to restore it. It could be huge – potentially 32 TB. In contrast, if you delete a smallfile data file, it is much smaller – maximum 32 GB.

How often do you accidentally delete a data file? OK – some of us might know a horror story from back in the days – but it is very rare.

Should it happen, you can switch to your standby database while restoring the data file.

Plus, if you use Oracle Automatic Storage Management (ASM), you can’t accidentally delete a data file. If a data file is in use by a database, you can’t delete the file in asmcmd.

Incompatibility With File System

I know at least one operating system, which, in older versions, had a maximum limit of files of 16 TB. This is no longer a problem in modern operating systems. Nor is it a problem if you use ASM.

Someone even claimed it was the case in certain tape systems, although I couldn’t verify it.

It’s Always Been Like This

In the old days, I understand why you would want to use smallfile tablespaces. But not anymore. The downsides don’t exist anymore.

But, it’s hard to migrate to bigfile tablespaces!

No, it is not.

In recent versions of Oracle Database, you can move tables into a new tablespace without downtime. The same applies to indexes which you can rebuild into a new tablespace. It’s all online operations. No downtime, no interruptions!

LOB segments might be a little more tricky. DBMS_REDEFINITION could be a solution.

Some of these options require additional licenses. Always check the license guide before you start to use a new feature.

Still, I do understand that for existing databases, you don’t want to migrate. But for new tablespaces and new databases, I’d always go with bigfile tablespaces.

Let Me Know

I don’t see a reason for using smallfile tablespaces anymore.

But I’m curious. Why are you not using bigfile tablespaces? Please leave a comment with your reason or concern.

By the way – usually, an Oracle Database can hold only a certain amount of data files. When you start to go into Petabytes, you’ll need bigfile tablespaces.

Updates to Blog Post

The More Data Files, the Longer Switchover Time

Ludovico Caldara, the Data Guard PM, pointed out on LinkedIn, that the more data files you have, the longer a Data Guard switchover takes.

Contention When File Expands

dbroots left a comment referencing this MOS note: Alter Tablespace Resize on Bigfile Tablespace Causes Sessions to Hang with ‘Enq: TX – contention’ and ‘Buffer busy waits’ (Doc ID 2089689.1).

For very busy systems, you might see a short wait event while the data file expands in a bigfile tablespace. If it becomes too big a problem, you need to expand your data file in off-peak periods.

Further Reading

XTTS: Bigfile Tablespaces

What if the database you want to migrate has bigfile tablespaces? Bigfile tablespaces are very often used in very large databases. Do they influence on the migration using cross-platform transportable tablespaces and incremental backups?

What Is It?

First, let’s briefly recap what a bigfile tablespace is:

A bigfile tablespace is a tablespace with a single, but potentially very large (up to 4G blocks) data file. Traditional smallfile tablespaces, in contrast, can contain multiple data files, but the files cannot be as large.

The benefits of bigfile tablespaces are the following:

  • A bigfile tablespace with 8K blocks can contain a 32 terabyte data file…

Important to note is that a bigfile tablespace contains one big data file. That file can be huge.

What Do You Normally Do?

When RMAN backs up a database or a tablespace it will parallelize by using several channels – each channel will process one or more data files. Imagine a 32 TB data file (from a bigfile tablespace). One RMAN channel will be allocated and needs to process that data file alone. That will take a while!

To solve that multisection backup was implemented. That allows multiple channels to work on the same data file. You can enable multisection backup by using the clause section size.

Backup

The initial, level 0 backup of the source database is executed by the Perl script during the migration. The Perl script generates the RMAN backup commands on-the-fly, and it does not specify a section size. In addition, it is not possible to specify section size as a default channel configuration (see RMAN show all command).

So there is no way to enable the use of multisection backup. Currently, multisection backup is simply not supported by the Perl script.

Now What

If multisection backup is essential to your migration, I suggest you create a Service Request and ask for an enhancement. The more customers request it, the more likely it is that the feature will be added.

If you have bigfile tablespaces you have only one option. Use multiple Perl scripts. It is a good workaround if you have many bigfile tablespaces. The workaround probably won’t add much value if you only have one.

I have another blog post describing the use of multiple Perl scripts.
