How to Solve DCS-12300:Failed to Clone PDB During Remote Clone (DBT-19407)

A customer reached out to me:

I want upgrade a PDB from Oracle Database 19c to 23ai. It’s in a Base Database Service in OCI. I use the Remote clone feature in the OCI console but it fails with DCS-12300 because IMEDIA component is installed.

The task:

  • Clone a PDB using the OCI Console Remote clone feature
  • From a CDB on Oracle Database 19c to another CDB on Oracle Database 23ai
  • Upgrade the PDB to Oracle Database 23ai

Let’s see what happens when you clone a PDB:

Error message from OCI console when remote cloning a PDB to 23ai using cloud tooling

It fails, as explained by the customer.

Let’s dig a little deeper. Connect as root to the target system and check the DCS agent.

$ dbcli list-jobs

ID                                       Description                                                                 Created                             Status
---------------------------------------- --------------------------------------------------------------------------- ----------------------------------- ----------
...
6e1fa60c-8572-4e08-ba30-cafb705c195e     Remote Pluggable Database:SALES from SALES in db:CDB23                      Tuesday, September 24, 2024, 05:04:13 UTC Failure

$ dbcli describe-job -i 6e1fa60c-8572-4e08-ba30-cafb705c195e

Job details
----------------------------------------------------------------
                     ID:  6e1fa60c-8572-4e08-ba30-cafb705c195e
            Description:  Remote Pluggable Database:SALES from SALES in db:CDB23
                 Status:  Failure
                Created:  September 24, 2024 at 5:04:13 AM UTC
               Progress:  35%
                Message:  DCS-12300:Failed to clone PDB SALES from remote PDB SALES. [[FATAL] [DBT-19407] Database option (IMEDIA) is not installed in Local CDB (CDB23).,
 CAUSE: The database options installed on the Remote CDB(CDB19_979_fra.sub02121342350.daniel.oraclevcn.com) m
             Error Code:  DCS-12300
                  Cause:  Error occurred during cloning the remote PDB.
                 Action:  Refer to DCS agent log, DBCA log for more information.

...

What’s Going on?

First, IMEDIA stands for interMedia and is an old name for the Multimedia component. The ID of Multimedia is ORDIM.

Oracle desupported the Multimedia component:

Desupport of Oracle Multimedia Oracle Multimedia is desupported in Oracle Database 19c, and the implementation is removed. … Oracle Multimedia objects and packages remain in the database. However, these objects and packages no longer function, and raise exceptions if there is an attempt made to use them.

In the customer’s and my case, the Multimedia component is installed in the source PDB, but not present in the target CDB. The target CDB is on Oracle Database 23ai where this component is completely removed.

If you plug in a PDB that has more components than the CDB, you get a plug-in violation, and that’s causing the error.

Here’s how you can check whether Multimedia is installed:

select   con_id, status
from     cdb_registry
where    comp_id='ORDIM'
order by 1;

Solution 1: AutoUpgrade

The best solution is to use AutoUpgrade. Here’s a blog post with all the details.

AutoUpgrade detects that multimedia is already present in the preupgrade phase. Here’s an extract from the preupgrade log file:

INFORMATION ONLY
  ================
    7.  Follow the instructions in the Oracle Multimedia README.txt file in <23
      ORACLE_HOME>/ord/im/admin/README.txt, or MOS note 2555923.1 to determine
      if Oracle Multimedia is being used. If Oracle Multimedia is being used,
      refer to MOS note 2347372.1 for suggestions on replacing Oracle
      Multimedia.

      Oracle Multimedia component (ORDIM) is installed.

      Starting in release 19c, Oracle Multimedia is desupported. Object types
      still exist, but methods and procedures will raise an exception. Refer to
      23 Oracle Database Upgrade Guide, the Oracle Multimedia README.txt file
      in <23 ORACLE_HOME>/ord/im/admin/README.txt, or MOS note 2555923.1 for
      more information.

When AutoUpgrade plugs in the PDB with Multimedia, it’ll see the plug-in violation. But AutoUpgrade is smart and knows that Multimedia is special. It knows that during the upgrade, it will execute the Multimedia removal script. So, it disregards the plug-in violation until the situation is resolved.

AutoUpgrade also handles the upgrade, so it’s a done deal. Easy!

Solution 2: Remove Multimedia

You can also manually remove the Multimedia component in the source PDB before cloning.

I grabbed these instructions from Mike Dietrich’s blog. They work for a 19c CDB:

cd $ORACLE_HOME/rdbms/admin
#First, remove ORDIM in all containers, except root
$ORACLE_HOME/perl/bin/perl catcon.pl -n 1 -C 'CDB$ROOT' -e -b imremdo_pdbs -d $ORACLE_HOME/ord/im/admin imremdo.sql
#Recompile
$ORACLE_HOME/perl/bin/perl catcon.pl -n 1 -e -b utlrp -d '''.''' utlrp.sql
#Last, remove ORDIM in root
$ORACLE_HOME/perl/bin/perl catcon.pl -n 1 -c 'CDB$ROOT' -e -b imremdo_cdb -d $ORACLE_HOME/ord/im/admin imremdo.sql
#Recompile
$ORACLE_HOME/perl/bin/perl catcon.pl -n 1 -e -b utlrp -d '''.''' utlrp.sql
#Remove leftover package in all containers
echo "drop package SYS.ORDIMDPCALLOUTS;" > vi dropim.sql
$ $ORACLE_HOME/perl/bin/perl $ORACLE_HOME/rdbms/admin/catcon.pl -n 1 -e -b dropim -d '''.''' dropim.sql

Without the Multimedia component cloning via the cloud tooling works, but you are still left with a PDB that you attend to.

If you’re not using AutoUpgrade, you will use a new feature called replay upgrade. The CDB will see that the PDB is a lower-version and start an automatic upgrade. However, you still have some manual pre- and post-upgrade tasks to do.

One of the reasons I prefer using AutoUpgrade.

Further Reading

For those interested, here are a few links to Mike Dietrich’s blog on components and Multimedia in particular:

Zero Downtime Migration – Logical Online Migration and Testing

How can you test your OCI database before going live? With Logical Online migration it is possible using Flashback Database, restore or cloning. Let’s explore the options.

Flashback Database

Using Flashback Database is the easiest option and it is supported on all target platforms except Autonomous Database (shared and dedicated). In addition, your target database must be Enterprise Edition.

Does Oracle GoldenGate support Flashback Database? You can find the answer in the MOS note Does Goldengate Support Oracle RDBMS Flashback Features? (Doc ID 966212.1):

In a situation where there are only Replicats on a system, then FLASHBACK DATABASE… is fully supported if the Replicats are all using a checkpoint table and the trail files are available that go as far back as the flashback.

When you do Logical Online migrations you only have replicat process in your target database. In addition, checkpoint tables are enabled by default. All good!

Flashback Database – How To

  1. Stop replicat process by logging on to the GoldenGate hub and navigate to the Target Administration Server: How to stop replicat process in Oracle GoldenGate Microservices Architecture Hub
  2. Set a guaranteed restore point in the target PDB (named tgtpdb):
alter session set container=tgtpdb;
create restore point grp4test guarantee flashback database;
  1. Do your tests.
  2. Revert the changes by issuing a FLASHBACK PLUGGABLE DATABASE command:
alter session set container=cdb$root;
alter pluggable database tgtpdb close immediate;
flashback pluggable database tgtpdb to restore point grp4test;
alter pluggable database tgtpdb open resetlogs;
  1. Restart replicat process: How to start replicat process in Oracle GoldenGate Microservices Architecture Hub

The above procedure uses flashback of the pluggable database. This feature was introduced in Oracle Database 12.2. If your target database is 12.1 or older, you have to flashback the entire CDB. If your target database is a non-CDB database, you have to flashback back the entire database.

Restore

Backup/restore is also an option. In OCI it is easy to backup and restore, however, it does take longer than using Flashback Database. But the good thing is that you get to test your OCI backup and recovery strategy.

For Autonomous Database you can use the automatic backups which are enabled by default. In the other Database Cloud Offerings, you must enable automatic backup yourself.

Restore – How To

  1. Stop replicat process (see above)
  2. Create backup (or rely on automatic backup)
  3. Do your tests
  4. Restore backup
  5. Restart replicat process (see above)

Clone

Cloning the database or the entire DB System is also an option. A benefit is that the GoldenGate replication can continue while you are doing the tests. When you use Flashback Database and restore the replication must be stopped. Trail files will accumulate on disk and at one point the target database will be very busy catching up with the lag. For very huge and active systems it might be desirable to work on a clone. However, cloning to a new system mean that you are no longer testing in that specific database that will be your future production database. Also, cloning involves creating new DB Systems which has a cost.

Clone – How To

  1. Clone database or DB System
  2. Do your tests
  3. Discard database or DB System

Conclusion

Before going live in your new OCI database, you should test it. With Logical Online method it is easy, and you can use well-known techniques. If you combine it with the recommendations from our webinar Performance Stability, Tips and Tricks and Underscores, you are well underway towards a successful migration.
