How to Upgrade Oracle Database and Replace the Operating System

A reader asked me for advice on upgrading Oracle Database and replacing the underlying operating system.

  • Currently on Oracle Database 12.1.0.2
  • Currently on Windows Server 2012
  • Upgrade to Oracle Database 19c
  • Move to new servers with Microsoft Windows Server 2022

What’s the recommended approach for transitioning to Oracle 19c on Windows 2022?

Oracle Data Guard

My first option is always Oracle Data Guard. It is often a superior option. You move the entire database, and the only interruption is a Data Guard switchover.

In this case, where the reader needs to replace the operating system, the first thing to check is platform certifications. Always check platform certifications on My Oracle Support. It has the most up-to-date information.

Here is an overview of the platform certification for Oracle Database 12.1.0.2 and 19c.

Oracle Database 12.1.0.2 Oracle Database 19c
Windows Server 2008
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2 Windows Server 2012 R2
Windows Server 2016
Windows Server 2019
Windows Server 2022

Oracle Database 19c does not support the current platform, Windows Server 2012. Thus, the reader can’t set up a standby database on the new servers and transition via a regular switchover.

Windows Server 2012 R2

Let’s imagine the current servers were using Windows Server 2012 R2. Both database releases support this platform. I would recommend this approach:

  1. Upgrade to Oracle Database 19c on current servers.
  2. Set up new servers with Windows Server 2022.
  3. Create standby database on new server.
  4. Transition to new servers with a regular Data Guard switchver.

This approach requires two maintenance windows. Yet, it is still my favorite because it is very simple.

RMAN Backups

You could also use RMAN and incremental backups. You don’t need much downtime – just the time necessary for a final incremental backup and restore. Like with Data Guard, you bring over the entire database.

RMAN can restore backups from a previous version, and you can use that to your advantage.

  1. Provision new servers with just Oracle Database 19c.
  2. Backup on 12.1.0.2.
  3. Restore and recover the database on the new servers with Oracle Database 19c binaries.
  4. After the final incremental backup, open the new database in upgrade mode and perform the upgrade.

We covered this approach in one of our webinars; you can also find details in this blog post.

Move Storage

You can also unmount the storage from the old server, and attach it to the new server.

  1. Run AutoUpgrade in analyze mode to determine upgrade readiness.
  2. Down time starts.
  3. Run AutoUpgrade in fixup mode to fix any issues preventing the upgrade from starting.
  4. Cleanly shut down the source database.
  5. Move the storage to the new server.
  6. Start the database on the new server in upgrade mode.
  7. Start AutoUpgrade in upgrade mode to complete the upgrade.

This is just a high-level overview. For a real move, there are many more intermediate steps.

Be sure to have a proper rollback plan. You are re-using the data files and AutoUprade in upgrade mode does not create a guaranteed restore point.

Data Pump

Data Pump is also a viable option, especially for smaller, less complex databases. It also enables you to restructure your database, for example:

  • Transform old BasicFile LOBs to SecureFile
  • Implement partitioning
  • Exclude data (for archival)
  • You can import directly into a higher release and even directly into a PDB.

But – the larger the database, the longer downtime (generally speaking).

When you use Data Pump for upgrades, I recommend using a full database export.

Full Transportable Export/Import

You can also use transportable tablespaces for upgrades. You can even migrate directly into a PDB on Oracle Database 19c.

The downside of transportable tablespace is that you must copy the data files to the new system.

But often, you can unmount the storage and mount the storage on the new servers. This avoids the cumbersome process of copying the data files to the new system.

Another approach is to combine transportable tablespaces with incremental backups, if you want to lower the downtime needed. This approach leaves the original database untouched, leaving you with a perfect rollback option.

Oracle GoldenGate

You could also use Oracle GoldenGate. But for most upgrades, it is overkill, partly because of the restrictions and considerations. I see this as a sensible option only if you have very strict downtime or fallback requirements.

Conclusion

What is the best option?

It depends…

This post helps you make the best decision for your organization.

Oracle Data Pump and Compression – Also Without a License

Whenever you use Data Pump to export from Oracle Database, you should use compression. It’s conveniently built into Data Pump.

Pros:

  • The dump file is much smaller:
    • Less disk space is needed.
    • Easier to transfer over the network.
  • Often it is faster to use compression when you measure the entire workflow (export, transfer, and import).
  • Imports are often faster because less data needs to be written from disk.

Cons:

How Do I Enable Data Pump Compression

You simply set COMPRESSION option:

$ expdp ... compression=all

You use COMPRESSION option only for exports. When you import, Data Pump handles it automatically.

You only need a license for Advanced Compression Option when you use compression during export. You don’t need a license to import a compressed dump file.

Medium Is a Good Compression Algorithm

I recommend you use the medium compression algorithm:

$ expdp ... compression=all compression_algorithm=medium

Our experience and tests show that it best balances between compression ratio and CPU.

Here are the results of a test my team did:

Algorithm File Size (MB) Compression Ratio Elapsed Time
NONE 5.800 1,0 2m 33s
BASIC 705 8,2 3m 03s
LOW 870 6,6 3m 11s
MEDIUM 701 8,2 3m 01s
HIGH 509 11,3 12m 16s

I would recommend high algorithm only if you need to transfer over a really slow network.

But I Don’t Have a License

gzip

You can still compress the dump file but not using Data Pump. Use OS utilities. In this case, I recommend splitting the dump file into pieces. It is easier to handle, and you can start transferring the dump files as they are compressed:

$ expdp ... filesize=5G dumpfile=myexp%L.dmp
$ gzip -r /u01/app/oracle/dpdir

Now, you transfer the files, uncompress and import:

[target]$ gunzip -r /u01/app/oracle/dpdir
[target]$ impdp ...

rsync

Another option is to use rsync. It has the option to compress the dump file over the network only:

$ expdp ... filesize=5G dumpfile=myexp%L.dmp
$ rsync -z ...

Cheatsheet

If you have the proper license, use Data Pump compression during export:

$ expdp ... compression=all compression_algorithm=medium

If you don’t have a license, compress the dump file over the wire only:

$ rsync -z ....

Don’t combine Data Pump compression and gzip/rsync! Compressing compressed stuff is not a good idea.

XTTS: Introduction – Minimal Downtime Migration with Full Transportable Export Import and Incremental Backups

If you need to migrate a database to the cloud or anywhere else for that matter, you should consider using cross-platform transportable tablespaces and incremental backup (XTTS). Even for really large databases – 10s or 100s of TB – you can still migrate with minimal downtime. And it works across different endian formats. In fact, for the majority of cross-endian projects this method is used.

In addition to minimal downtime, XTTS has the following benefits:

  • You can implicitly upgrade the database by migrating directly into a higher release
  • You can migrate from a non-CDB and into a PDB
  • You can keep downtime at a minimum by using frequent incremental backups
  • You can migrate across endianness – e.g. from AIX or Solaris to Oracle Linux

Endian-what?

Endianness is determined by the operating system. Simplified, it determines in which order bytes are stored in memory:

  • Big endian: stores the most significant byte of a word at the smallest memory address.
  • Little endian: stores the least-significant byte at the smallest address.

Wikipedia has an article for the interested reader.

Which platform uses which endian format? There is a query for that:

SQL> select platform_name, endian_format from v$transportable_platform;

If your source and target platform does not use the same endian format, then you need a cross-endian migration.

How Does It Work

To concept is explained in this video on our YouTube Channel:

Basically, you need to migrate two things:

  • Data
  • Metadata

Data

The data itself is stored in data files and you will be using transportable tablespaces for this. Since the source and target platform are not the same, the data files must be converted to the new format. Only the data files that make up user tablespaces are transported. The system tablespaces, like SYSTEM and SYSAUX, are not transported.

If you have a big database, it will take a lot of time to copy the data files. Often this is a problem because the downtime window is short. To overcome this you can use a combination of RMAN full backups (backup set or image copies) and incremental backups.

There are a few ways to do this which is covered in the following MOS notes:

The first two methods are using version 3 of a Perl script (xttdriver.pl), whereas the last method uses version 4 of the same Perl script. Version 4 offers a much simplified method and I will use that version for this blog post series.

Version 4 of the Perl script has a list of requirements. If your project can’t meet these requirements, check if the previous version 3 can be used.

Metadata

Transferring the data files is just part of the project. Information on what is inside the data files, the metadata, is missing because the system tablespaces were not transferred. The metadata is needed by the target database, otherwise, the data files are useless. The Transportable Tablespace concept as a whole does not work for system tablespaces, but instead we can use Data Pump.

You can use either:

  • Traditional transportable tablespace
  • Or, the newer full transportable export/import (FTEX)

For this blog post series, I am only focusing on FTEX. But if you run into problems with FTEX, or if you can’t meet any of the FTEX requirements, you should look into the traditional transportable tablespace method.

Here are a few examples of metadata that Data Pump must transfer:

  • Users
  • Privileges
  • Packages, procedudes and functions
  • Table and index defintions (the actual rows and index blocks are in the data files)
  • Temporary tables
  • Views
  • Synonyms
  • Directories
  • Database links
  • And so forth

Conclusion

By using a combination of cross-platform transportable tablespaces and incremental backups, you can migrate even huge databases to the cloud. And it even works for cross-endian migrations, like AIX or Solaris to Oracle Linux.

You can watch our YouTube playlist and watch videos on cross-platform transportable tablespaces.
